1. Technical Documentation for FATES

FATES is the “Functionally Assembled Terrestrial Ecosystem Simulator”. It is an external module which can run within a given “Host Land Model” (HLM). Currently (November 2017) implementations are supported in both the Community Land Model of the Community Terrestrial Systems Model (CLM-CTSM) and in the Energy Exascale Earth Systems Model (E3SM) Land Model (ELM).

FATES was derived from the CLM Ecosystem Demography model (CLM(ED)), which was documented in:

Fisher, R. A., Muszala, S., Verteinstein, M., Lawrence, P., Xu, C., McDowell, N. G., Knox, R. G., Koven, C., Holm, J., Rogers, B. M., Spessa, A., Lawrence, D., and Bonan, G.: Taking off the training wheels: the properties of a dynamic vegetation model without climate envelopes, CLM4.5(ED), Geosci. Model Dev., 8, 3593-3619, https://doi.org/10.5194/gmd-8-3593-2015, 2015.

and this technical note was first published as an appendix to that paper.

https://pdfs.semanticscholar.org/396c/b9f172cb681421ed78325a2237bfb428eece.pdf

1.1. Authors of FATES code and technical documentation.

Rosie A. Fisher 1,2, Ryan G. Knox 3, Charles D. Koven 3, Gregory Lemieux 3, Chonggang Xu 4, Brad Christofferson 5, Jacquelyn Shuman 1, Maoyi Huang 6, Erik Kluzek 1, Benjamin Andre 1, Jessica F. Needham 3, Jennifer Holm 3, Marlies Kovenock 7, Abigail L. S. Swann 7, Stefan Muszala 1, Shawn P. Serbin 8, Qianyu Li 8, Mariana Verteinstein 1, Anthony P. Walker 11, Alan di Vittorio 3, Yilin Fang 9, Yi Xu 6, Junyan Ding:sup:12

1 Climate and Global Dynamics Division, National Center for Atmospheric Research, Boulder, CO, USA

2 Centre Européen de Recherche et de Formation Avancée en Calcul Scientifique, Toulouse, France

3 Climate and Ecosystem Sciences Division, Lawrence Berkeley National Laboratory, Berkeley, CA, USA

4 Earth and Environmental Sciences Division, Los Alamos National Laboratory, Los Alamos, NM, USA

5 Department of Biology, University of Texas, Rio Grande Valley, Edinburg, TX, USA

6 Atmospheric Sciences and Global Change Division, Pacific Northwest National Laboratory, Richland, WA, USA

7 Department of Biology, University of Washington, Seattle, WA, USA

8 Environmental and Climate Sciences Department, Brookhaven National Laboratory, Upton, NY, USA

9 Energy and Environment Directorate, Pacific Northwest National Laboratory, Richland, WA, USA

10 Jet Propulsion Laboratory, Pasadena, CA, USA

11 Climate Change Science Institute, Environmental Sciences Division, Oak Ridge National Laboratory, Oak Ridge, TN, USA

12 Earth & Biological Sciences, Pacific Northwest National Laboratory, Richland, WA, USA

1.2. Introduction

The Ecosystem Demography (‘ED’), concept within FATES is derived from the work of Moorcroft et al. (2001)

and is a cohort model of vegetation competition and co-existence, allowing a representation of the biosphere which accounts for the division of the land surface into successional stages, and for competition for light between height structured cohorts of representative trees of various plant functional types.

The implementation of the Ecosystem Demography concept within FATES links the surface flux and canopy physiology concepts in the CLM/ELM with numerous additional developments necessary to accommodate the new model also documented here. These include a version of the SPITFIRE (Spread and InTensity of Fire) model of Thonicke et al. (2010), and an adoption of the concept of Perfect Plasticity Approximation approach of Purves et al. 2008, Lichstein et al. 2011 and Weng et al. 2014, in accounting for the spatial arrangement of crowns. Novel algorithms accounting for the fragmentation of coarse woody debris into chemical litter streams, for the physiological optimisation of canopy thickness, for the accumulation of seeds in the seed bank, for multi-layer multi-PFT radiation transfer, for drought-deciduous and cold-deciduous phenology, for carbon storage allocation, and for tree mortality under carbon stress, are also included and presented here.

Numerous other implementations of the Ecosystem Demography concept exist (See Fisher et al. (2018) for a review of these) Therefore, to avoid confusion between the concept of ‘Ecosystem Demography’ and the implementation of this concept in different models, the CLM(ED) implementation described by Fisher et al. (2015) will hereafter be called ‘FATES’ (the Functionally Assembled Terrestrial Ecosystem Simulator).

1.3. The representation of ecosystem heterogeneity in FATES

The terrestrial surface of the Earth is heterogeneous for many reasons, driven by variations in climate, edaphic history, ecological variability, geological forcing and human interventions. Land surface models represent this variability first by introducing a grid structure to the land surface, allowing different atmospheric forcings to operate in each grid cell, and subsequently by representing ‘sub-grid’ variability in the surface properties. In the CLM, the land surface is divided into numerous ‘landunits’ corresponding to the underlying condition of the surface (e.g. soils, ice, lakes, bare ground) and then ‘columns’ referring to elements of the surface that share below ground resources (water & nutrients). Within the soil landunit, for example, there are separate columns for crops, and for natural vegetation, as these are assumed to use separate resource pools. The FATES model at present only operates on the naturally vegetated column. The soil column is sub-divided into numerous tiles, that correspond to statistical fractions of the potentially vegetated land area. In the CLM 4.5 (and all previous versions of the model), sub-grid tiling operates on the basis of plant functional types (PFTs). That is, each piece of land is assumed to be occupied by only one plant functional type, with multiple PFT-specific tiles sharing a common soil water and nutrient pool. This PFT-based tiling structure is the standard method used by most land surface models deployed in climate prediction.

The introduction of the Ecosystem Demography concept introduces significant alterations to the representation of the land surface in the CLM. In FATES, the tiling structure represents the disturbance history of the ecosystem. Thus, some fraction of the land surface is characterized as ‘recently disturbed’, some fraction has escaped disturbance for a long time, and other areas will have intermediate disturbances. Thus the ED concept essentially discretizes the trajectory of succession from disturbed ground to ‘mature’ ecosystems. Within FATES, each “disturbance history class” is referred to as a ‘patch’. The word “patch” has many possible interpretations, so it is important to note that: there is no spatial location associated with the concept of a ‘patch’ . It refers to a fraction of the potential vegetated area consisting of all parts of the ecosystem with similar disturbance history.

The ‘patch’ organizational structure in CLM thus replaces the previous ‘PFT’ structure in the organization heirarchy. The original hierarchical land surface organizational structure of CLM as described in Oleson et al. 2013 may be depicted as:

\mathbf{gridcell} \left\{
\begin{array}{cc}
\mathbf{landunit} &   \\
\mathbf{landunit} &\left\{
\begin{array}{ll}
\mathbf{column}&\\
\mathbf{column}&\left\{
\begin{array}{ll}
\mathbf{pft}&\\
\mathbf{pft}&\\
\mathbf{pft}&\\
\end{array}\right.\\
\mathbf{column}&\\
\end{array}\right.\\
\mathbf{landunit} &   \\
\end{array}\right.

and the new structure is altered to the following:

\mathbf{gridcell} \left\{
\begin{array}{cc}
\mathbf{landunit} &   \\
\mathbf{landunit} &\left\{
\begin{array}{ll}
\mathbf{column}&\\
\mathbf{column}&\left\{
\begin{array}{ll}
\mathbf{patch}&\\
\mathbf{patch}&\\
\mathbf{patch}&\\
\end{array}\right.\\
\mathbf{column}&\\
\end{array}\right.\\
\mathbf{landunit} &   \\
\end{array}\right.

Thus, each gridcell becomes a matrix of ‘patches’ that are conceptualized by their ‘age since disturbance’ in years. This is the equivalent of grouping together all those areas of a gridcell that are ‘canopy gaps’, into a single entity, and all those areas that are ‘mature forest’ into a single entity.

1.3.1. Cohortized representation of tree populations

Each common-disturbance-history patch is a notional ecosystem that might in reality contain numerous individual plants which vary in their physiological attributes, in height and in spatial position. One way of addressing this heterogeneity is to simulate a forest of specific individuals, and to monitor their behavior through time. This is the approach taken by “gap” and individual-based models (Smith et al. 2001, Sato et al. 2007, Uriarte et al. 2009, Fyllas et al. 2014). The depiction of individuals typically implies that the outcome of the model is stochastic. This is because we lack the necessary detailed knowledge to simulate the individual plant’s fates. Thus gap models imply both stochastic locations and mortality of plants. Thus, (with a genuinely random seed) each model outcome is different, and an ensemble of model runs is required to generate an average representative solution. Because the random death of large individual trees can cause significant deviations from the mean trajectory for a small plot (a typical simulated plot size is 30m x 30 m) the number of runs required to minimize these deviations is large and computationally expensive. For this reason, models that resolve individual trees typically use a physiological timestep of one day or longer (e.g. Smith et al. 2001, Xiaidong et al. 2005, Sato et al. 2007

The approach introduced by the Ecosystem Demography model Moorcroft et al. 2001 is to group the hypothetical population of plants into “cohorts”. In the notional ecosystem, after the land-surface is divided into common-disturbance-history patches, the population in each patch is divided first into plant functional types (the standard approach to representing plant diversity in large scale vegetation models), and then each plant type is represented as numerous height classes. Importantly, for each PFT/height class bin, we model *one* representative individual plant, which tracks the average properties of this `cohort` of individual plants. Thus, each common-disturbance-history patch is typically occupied by a set of cohorts of different plant functional types, and different height classes within those plant functional types. Each cohort is associated with a number of identical trees, n_{coh} (where {coh} denotes the identification or index number for a given cohort)..

The complete hierarchy of elements in FATES is therefore now described as follows:

\mathbf{gridcell}\left\{
\begin{array}{cc}
\mathbf{landunit} &   \\
\mathbf{landunit} &\left\{
\begin{array}{ll}
\mathbf{column}&\\
\mathbf{column}&\left\{
\begin{array}{ll}
\mathbf{patch}&\\
\mathbf{patch}&\left\{
\begin{array}{ll}
\mathbf{cohort}&\\
\mathbf{cohort}&\\
\mathbf{cohort}&\\
\end{array}\right.\\
\mathbf{patch}&\\
\end{array}\right.\\
\mathbf{column}&\\
\end{array}\right.\\
\mathbf{landunit} &   \\
\end{array}\right.

1.3.2. Discretization of cohorts and patches

Newly disturbed land and newly recruited seedlings can in theory be generated at each new model timestep as the result of germination and disturbance processes. If the new patches and cohorts established at every timestep were tracked by the model structure, the computational load would of course be extremely high (and thus equivalent to an individual-based approach). A signature feature of the ED model is the system by which functionally equivalent patches and cohorts are fused into single model entities to save memory and computational time.

This functionality requires that criteria are established for the meaning of functional equivalence, which are by necessity slightly subjective, as they represent ways of abstracting reality into a more tractable mathematical representation. As an example of this, for height-structured cohorts, we calculate the relativized differences in height (h_{coh}, m) between two cohorts of the same pft, p and q as

d_{hite,p,q} = \frac{\mathrm{abs}(h_{p-}h_{q})}{\frac{1}{2}(h_{p}+h_{q})}

If d_{hite,p,q} is smaller than some threshold t_{ch}, and they are of the same plant functional type, the two cohorts are considered equivalent and merged to form a third cohort r, with the properties of cohort p and q averaged such that they conserve mass. The model parameter t_{ch} can be adjusted to adjust the trade-off between simulation accuracy and computational load. There is no theoretical optimal value for this threshold but it may be altered to have finer or coarser model resolutions as needed.

Similarly, for common-disturbance-history patches, we again assign a threshold criteria, which is then compared to the difference between patches m and n, and if the difference is less than some threshold value (t_{p}) then patches are merged together, otherwise they are kept separate. However, in contrast with height-structured cohorts, where the meaning of the difference criteria is relatively clear, how the landscape should be divided into common-disturbance-history units is less clear. Several alternative criteria are possible, including Leaf Area Index, total biomass and total stem basal area.

In this implementation of FATES we assess the amount of above-ground biomass in each PFT/plant diameter bin. Biomass is first grouped into fixed diameter bins for each PFT (ft) and a significant difference in any bin will cause patches to remain separated. This means that if two patches have similar total biomass, but differ in the distribution of that biomass between diameter classes or plant types, they remain as separate entities. Thus

B_{profile,m,dc,ft} = \sum_{d_{c,min}}^{d_{c,max}} (B_{ag,coh}n_{coh})

B_{profile,m,dc,ft} is the binned above-ground biomass profile for patch m,d_{c} is the diameter class. d_{c,min} and d_{c,max} are the lower and upper boundaries for the d_{c} diameter class. B_{ag,coh} and n_{coh} depict the biomass (KgC m-2) and the number of individuals of each cohort respectively. A difference matrix between patches m and n is thus calculated as

d_{biomass,mn,dc,ft} = \frac{\rm{abs}\it(B_{profile,m,hc,ft}-B_{profile,n,hc,ft})}{\frac{1}{2}(B_{profile,m,hc,ft}+B_{profile,n,hc,ft})}

If all the values of d_{biomass,mn,hc,ft} are smaller than the threshold, t_{p}, then the patches m and n are fused together to form a new patch o.

To increase computational efficiency and to simplify the coding structure of the model, the maximum number of patches is capped at P_{no,max}. To force the fusion of patches down to this number, the simulation begins with a relatively sensitive discretization of patches (t_{p} = 0.2) but if the patch number exceeds the maximum, the fusion routine is repeated iteratively until the two most similar patches reach their fusion threshold. This approach maintains an even discretization along the biomass gradient, in contrast to, for example, simply fusing the oldest or youngest patches together.

The area of the new patch (A_{patch,o}, m^{2}) is the sum of the area of the two existing patches,

A_{patch,o}  = A_{patch,n}  + A_{patch,m}

and the cohorts ‘belonging’ to patches m and n now co-occupy patch o. The state properties of m and n (litter, seed pools, etc. ) are also averaged in accordance with mass conservation .

1.3.3. Linked Lists: the general code structure of FATES

The number of patches in each natural vegetation column and the number of cohorts in any given patch are variable through time because they are re-calculated for each daily timestep of the model. The more complex an ecosystem, the larger the number of patches and cohorts. For a slowly growing ecosystem, where maximum cohort size achieved between disturbance intervals is low, the number of cohorts is also low. For fast-growing ecosystems where many plant types are viable and maximum heights are large, more cohorts are required to represent the ecosystem with adequate complexity.

In terms of variable structure, the creation of an array whose size could accommodate every possible cohort would mean defining the maximum potential number of cohorts for every potential patch, which would result in very large amounts of wasted allocated memory, on account of the heterogeneity in the number of cohorts between complex and simple ecosystems (n.b. this does still happen for some variables at restart timesteps). To resolve this, the cohort structure in FATES model does not use an array system for internal calculations. Instead it uses a system of linked lists where each cohort structure is linked to the cohorts larger than and smaller than itself using a system of pointers. The shortest cohort in each patch has a ‘shorter’ pointer that points to the null value, and the tallest cohort has a ‘taller’ pointer that points to the null value.

Instead of iterating along a vector indexed by coh, the code structures typically begin at the tallest cohort in a given patch, and iterate until a null pointer is encountered.

Using this structure, it is therefore possible to have an unbounded upper limit on cohort number, and also to easily alter the ordering of cohorts if, for example, a cohort of one functional type begins to grow faster than a competitor of another functional type, and the cohort list can easily be re-ordered by altering the pointer structure. Each cohort has pointers indicating to which patch and gridcell it belongs. The patch system is analogous to the cohort system, except that patches are ordered in terms of their relative age, with pointers to older and younger patches where cp_1 is the oldest:

1.3.4. Indices used in FATES

Some of the indices used in FATES are similar to those used in the standard CLM4.5 model; column (c), land unit(l), grid cell(g) and soil layer (j). On account of the additional complexity of the new representation of plant function, several additional indices are introduced that describe the discritization of plant type, fuel type, litter type, plant height, canopy identity, leaf vertical structure and fuel moisture characteristics. To provide a reference with which to interpret the equations that follow, they are listed here.

Parameter Symbol Parameter Name
ft Plant Functional Type
fc Fuel Class
lsc Litter Size Class
coh Cohort Index
patch Patch Index
cl Canopy Layer
z Leaf Layer
mc Moisture Class
o Plant Organ Index
s Nutrient Species Index

1.3.5. Cohort State Variables

The unit of allometry in the ED model is the cohort. Each cohort represents a group of plants with similar functional types and heights that occupy portions of column with similar disturbance histories. The state variables of each cohort therefore consist of several pieces of information that fully describe the growth status of the plant and its position in the ecosystem structure, and from which the model can be restarted. The state variables of a cohort are as follows:

Quantity Variable name Units Notes
Plant Functional Type {\it{ft}
_{coh}} integer
Number of Individuals n_{coh} n ha-2
Height h_{coh} m
Diameter \it{dbh_
{coh}} cm
Carbon Mass {C_{(o
,coh)}} Kg plant-1 leaf, fine-root sapwood, storage, structural, reproductive
Nutrient Mass {N_{(o
,s,coh)}} Kg plant-1 Optional depending on hypothesis. See PARTEH documentation.
Leaf memory {l_{memo
ry,coh}} Kg plant-1 Leaf mass when leaves are dropped
Phenological Status {S_{phen
,coh}} integer 1=leaves off. 2=leaves on
Canopy Layer Index cl_{coh
} integer 1=top canopy >1=understory
Canopy trimming C_{trim,
coh} fraction 1.0=max leaf area
Patch Index {p_{coh}
} integer To which patch does this cohort belong?

1.3.6. Patch State Variables

A patch, as discuss earlier, is a fraction of the landscape which contains ecosystems with similar structure and disturbance history. A patch has no spatial location. The state variables, which are ‘ecosystem’ rather than ‘tree’ scale properties, from which the model can be restarted, are as follows

Quantity Variable name Units Indexed By
Area \it{
A_{patch}} m2
Age age_
{patch} years
Seed seed_
{patch} KgC m-2 ft
Leaf Litter l_{l
itter,patch
} KgC m-2 ft
Root Litter r_{l
itter,patch
} KgC m-2 ft
AG Coarse Woody Debris {CWD}
_{A
G,patch} KgC m-2 Size Class (lsc)
BG Coarse Woody Debris {CWD}
_{B
G,patch} KgC m-2 Size Class (lsc)
Canopy Spread S_{c
,patch}   Canopy Layer
Column Index {l_{
patch}} integer

1.3.7. Model Structure

Code concerned with the Ecosystem Demography model interfaces with the CLM model in four ways: i) During initialization, ii) During the calculation of surface processes (albedo, radiation absorption, canopy fluxes) each model time step (typically half-hourly), iii) During the main invokation of the ED model code at the end of each day. Daily cohort-level NPP is used to grow plants and alter the cohort structures, disturbance processes (fire and mortality) operate to alter the patch structures, and all fragmenting carbon pool dynamics are calculated. iv) during restart reading and writing. The net assimilation (NPP) fluxes attributed to each cohort are accumulated throughout each daily cycle and passed into the ED code as the major driver of vegetation dynamics.

1.4. Initialization of vegetation from bare ground

If the model is restarted from a bare ground state (as opposed to a pre-existing vegetation state), the state variables above are initialized as follows. First, the number of plants per PFT is allocated according to the initial seeding density (S_{init}, individuals per m^{2}) and the area of the patch A_{patch}, which in the first timestep is the same as the area of the notional ecosystem A_{tot}. The model has no meaningful spatial dimension, but we assign a notional area such that the values of ‘n_{coh}’ can be attributed. The default value of A_{tot} is one hectare (10,000 m2), but the model will behave identically irrepective of the value of this parameter.

n_{coh,0} = S_{init}A_{patch}

Each cohort is initialized at the minimum canopy height h_{min,ft}, which is specified as a parameter for each plant functional type and denotes the smallest size of plant which is tracked by the model. Smaller plants are not considered, and their emergence from the recruitment processes is unresolved and therefore implicitly parameterized in the seedling establishment model.

The diameter of each cohort is then specified according to the height-diameter allometry function associated with the PFT of interest, see Table of Allometric Functions. The biomass pools for the newly recruited plant are then determined from the allometry equations that define the target (idealized) sizes for each pool.

Parameter Symbol Parameter Name Units Default Value
h_{min} Minimum plant height m 1.5
S_{init} Initial Planting density Individuals m-2

1.5. Allocation and Reactive Transport (PARTEH)

The Plant Allocation and Reactive Transport Extensible Hypotheses (PARTEH) is a suite of modules that handle the processes of allocation, transport and reactions (i.e. thos processes related to movement and change, yet perhaps not the genesis) of various arbitrary species (carbon, nutrients, toxins, etc) within the various organs of live vegetation. In FATES, these processes are resolved per unit plant, for each cohort.

1.6. Allometry and Growth Along Allometric Curves

In the previous section, Allocation and Reactive Transport (PARTEH), we covered the equations that describe how growth is implemented, as well the order of operations and logic of that forumlation. In this section, we will discuss the various allometric functions that generate the relative rates of change, as well as the target biomass quantities \grave{X}.

1.6.1. “Forced” Growth Along Allometric Curves

Growth specified by current PARTEH hypotheses follow along the allometric curves. A hypothetical example of a cohorts integration along such a curve is provided in the top panel of the diagram below. It is assumed that when a plant grows in stature, the structural biomass matches the target structural biomass for its size (DBH). This is represented by the grey dot sitting on the allometry line for structural biomass.

A state of being “on allometry” is consistent with the cohort (grey dot) existing on the allometric curve.

It is expected, and it is represented in the model, that due to either continuous or event based turnover, that biomass pools are continually depleted, thus pulling the grey dot straight down, away from the allometry line. Recall from the PARTEH description, that the first step in the growth algorithm is to use available carbon to replace these lost biomass pools (without increasing dbh) so that it is “on allometry”.

Also, all numerical integration has some amount of truncation error (step error). When FATES conducts the stature growth integration step, it typically uses Euler integration, because it is fast and simple. As a result, all biomass pools are projected along the tangent of the allometric curves from where they started. When the curvature parameters that govern these relationships are greater than 1, this results in continual “undershooting” of the actual target quantity. This is not a liability, firstly because growth is forced to be mass conservative. And secondly, to re-iterate the explanation above, upon the next growth step the algorithm will spend carbon to first get the pools back “on allometry”, before it projects along the tangent again. This is represented in the lower panel.

_images/growth_allometry_p1.png

However, we also have to accomodate for cases where the actual amount of biomass in the cohort’s pools are larger than the target sizes dictated by the cohort’s diameter. This can be visualized by the cohort residing somewhere above the line. This can happen for two reasons, 1) cohort fusion or 2) growth along allometric curves with curvature parameters (exponents) less than 1.

For woody plants, if a non-structural biomass pool is greater than the target pool size, the solution is simple. That pool is flagged to be ignored during the stature growth step, and eventually the cohort’s dbh will increase such that the target size exceeds its actual size again. This is visualized in the top panel of the diagram below.

There is a caveat here. The diameter must be “tied” to one of the biomass pools. And for woody plants, we choose structural carbon. And thus, we cannot flag to ignore structural carbon during stature growth since it is inextricably linked to diameter. Therefore, cohorts that have structural biomass that is greater than the target biomass dictated by its diameter, will have their DBH forceably increased (without increasing any biomass) until the allometric target matches the actual biomass. See the lower panel in the diagram below.

_images/growth_allometry_p2.png

Note, the explanation above was explained for woody plants, which tie diameter to structural biomass. For non-woody plants, such as grasses, we tie leaf biomass to diameter instead.

1.6.2. Allometric Relationships

FATES-PARTEH (in its base hypotheses) uses allometry to dictate the target biomass quantities of structure, sapwood, leaf, fine-root, reproduction and storage. Further, FATES also uses allometric relationships to define a cohort’s height and crown area. All of these target quantities are tied to diameter. Biomass pools may also be functionally dependent on other biomass pools, as long as a cyclical relationship is not generated, and can ultimately be related to diameter or other external factors. For instance, target root biomass is typically defined as proportional to leaf biomass. Target leaf biomass is dependent on height and a canopy trimming function, while crown area and above ground biomass are each also dependent on height.

The FATES code is written in a way that offers flexibility in how these relationships are cast. Each of these forumulations uses one or more user defined constant parameters, but it also allows for completely different functional forms. All of FATES allometric relationships can be found in the file FatesAllometryMod.F90.

Important note. Most allometry relationships from field research define total above ground biomass (AGB) as their estimated quantity instead of structural biomass. In FATES, since AGB is not a state-variable, it must be derived from the portions of several state variables. However, we make a simplification in FATES, and assume that the allometric relationships for AGB only contain structural wood and sapwood, and do not contain leaves, storage or reproductive tissues. Diagnostics on AGB will include all terms. Thus the allometric target for AGB contains the state targets and the fraction of above ground biomass (pft constant parameter) f_{a}.

(1.45)\grave{C}_{(AGB)} &= (\grave{C}_{(structure)} + \grave{C}_{(sapwood)}) * f_{agb}

Note that the diameter to height relationships all use an effective diameter, d_*. This is the minimum between the actual plant diameter, and the PFT specific parameter that specifies the diameter at which maximum height occurs d_{hmax}.

(1.46)d_* = \text{min}(d,d_{hmax})

The following table details the different allometric relationships that governs growth and stature, and the optional relationships and parameters associated with those relationships.

Table 1.6 Table of Allometric Functions
Reference Function
Diameter to Height
Power Function h = p_1 \cdot d_*^{p_2}
Obrien et al (1995) h = 10^{(log10(d_*) \cdot p_1+p_2)}
Poorter et al (2006) h = p_1 \cdot (1 - e^{p_2 \cdot d_*^{p_3}})
Martinez Cano et al (2019) h = (p_1 \cdot d_*^{p_2}) / (p_3+ d_*^{p_2})

Target Above Ground Biomass
Saldarriaga et al. (1998) \grave{C}_{agb} = f_{agb} \cdot p_1 \cdot h^{p_2} \cdot d^{p_3} \cdot \rho^{p_4}
2 Parameter power function \grave{C}_{agb} = p_1/\text{c2b} \cdot d^{p_2}
Chave et al. (2014) \grave{C}_{agb} = p_1/\text{c2b} \cdot (\rho \cdot d^{2} \cdot h)^{p_2}

Target Leaf Biomass (TBD)

Target Sapwood Biomass (TBD)

Target Fine-root Biomass (TBD)

Target Storage Biomass (TBD)

List of allometric relationships, their functional forms, and relevant parameters.

1.7. Canopy Structure and the Perfect Plasticity Approximation

During initialization and every subsequent daily ED timestep, the canopy structure model is called to determine how the leaf area of the different cohorts is arranged relative to the incoming radiation, which will then be used to drive the radiation and photosynthesis calculations. This task requires that some assumptions are made about 1) the shape and depth of the canopy within which the plant leaves are arranged and 2) how the leaves of different cohorts are arranged relative to each other. This set of assumptions are critical to model performance in ED-like cohort based models, since they determine how light resources are partitioned between competing plants of varying heights, which has a very significant impact on how vegetation distribution emerges from competition Fisher et al. 2010.

The standard ED1.0 model makes a simple ‘flat disk’ assumption, that the leaf area of each cohort is spread in an homogenous layer at one exact height across entire the ground area represented by each patch. FATES has diverged from this representation due to (at least) two problematic emergent properties that we identified as generating unrealistic behaviours espetially for large-area patches.

1. Over-estimation of light competition . The vertical stacking of cohorts which have all their leaf area at the same nominal height means that when one cohort is only very slightly taller than it’s competitor, it is completely shaded by it. This means that any small advantage in terms of height growth translates into a large advantage in terms of light competition, even at the seedling stage. This property of the model artificially exaggerates the process of light competition. In reality, trees do not compete for light until their canopies begin to overlap and canopy closure is approached.

2. Unrealistic over-crowding. The ‘flat-disk’ assumption has no consideration of the spatial extent of tree crowns. Therefore it has no control on the packing density of plants in the model. Given a mismatch between production and mortality, entirely unrealistic tree densities are thus possible for some combinations of recruitment, growth and mortality rates.

To account for the filling of space in three dimensions using the one-dimensional representation of the canopy employed by CLM, we implement a new scheme derived from that of Purves et al. 2008. Their argument follows the development of an individual-based variant of the SORTIE model, called SHELL, which allows the location of individual plant crowns to be highly flexible in space. Ultimately, the solutions of this model possess an emergent property whereby the crowns of the plants simply fill all of the available space in the canopy before forming a distinct understorey.

Purves et al. developed a model that uses this feature, called the ‘perfect plasticity approximation’, which assumes the plants are able to perfectly fill all of the available canopy space. That is, at canopy closure, all of the available horizontal space is filled, with negligible gaps, owing to lateral tree growth and the ability of tree canopies to grow into the available gaps (this is of course, an over-simplified but potential useful ecosystem property). The ‘perfect plasticity approximation’ (PPA) implies that the community of trees is subdivided into discrete canopy layers, and by extension, each cohort represented by FATES model is assigned a canopy layer status flag, C_L. In this version, we set the maximum number of canopy layers at 2 for simplicity, although is possible to have a larger number of layers in theory. C_{L,coh} = 1 means that all the trees of cohort coh are in the upper canopy (overstory), and C_{L,coh} = 2 means that all the trees of cohort coh are in the understorey.

In this model, all the trees in the canopy experience full light on their uppermost leaf layer, and all trees in the understorey experience the same light (full sunlight attenuated by the average LAI of the upper canopy) on their uppermost leaves, as described in the radiation transfer section (more nuanced versions of this approach may be investigated in future model versions). The canopy is assumed to be cylindrical, the lower layers of which experience self-shading by the upper layers.

To determine whether a second canopy layer is required, the model needs to know the spatial extent of tree crowns. Crown area, A_{crown}, m2, is defined as

A_{crown,coh}  =  S_{c,patch,cl}.dbh_{coh}^{(p_{e,leaf}-p_{e,leaf-crown})}

where A_{crown,coh} is the crown area of a single tree canopy (m2) and S_{c,patch,cl} is the ‘canopy spread’ parameter (unitless) of this canopy layer, which is assigned as a function of canopy space filling, discussed below. S_{c,patch,cl} is effectively a normalisation constant in the power law describing the relationship of crown area to dbh. However, this is not constant but varies by the canopy areae to ground area fraction. In contrast to Purves et al. 2008 , by default we use an exponent, identical to that for leaf biomass, p_{e,leaf}, not 2.0, such that tree leaf area index does not change as a function of diameter. The option is also available to modify the exponent using the difference parameter, p_{e,leaf-crown}.

To determine whether the canopy is closed, we calculate the total canopy area as:

A_{canopy} = \sum_{coh=1}^{nc,patch}{A_{crown,coh}.n_{coh}}

where nc_{patch} is the number of cohorts in a given patch. If the area of all crowns A_{canopy} (m2) is larger than the total ground area of a patch (A_{patch}), which typically happens at the end of the day, after growth and updated crown allometry is resolved in the model, then some fraction of each cohort is demoted to the understorey.

_images/Sorting_Schematic.png

Under these circumstances, the extra crown area A_{loss} (i.e., A_{canopy} - A_p) is moved into the understorey. For each cohort already in the canopy, we determine a fraction of trees that are moved from the canopy (L_c) to the understorey. L_c is calculated as Fisher et al. 2010

L_{c}= \frac{A_{loss,patch} w_{coh}}{\sum_{coh=1}^{nc,patch}{w_{coh}}} ,

where w_{coh} is a weighting of each cohort. There are two possible ways of calculating this weighting coefficient. The first, as described in Fisher et al. 2010, is to probabilistically weight cohorts based on their height h (m) and the competitive exclusion coefficient C_{e}

w_{coh}=h_{coh} C_{e}.

The higher the value of C_e the greater the impact of tree diameter on the probability of a given tree obtaining a position in the canopy layer. That is, for high C_e values, competition is highly deterministic. The smaller the value of C_e, the greater the influence of random factors on the competitive exclusion process, and the higher the probability that slower growing trees will get into the canopy. Appropriate values of C_e are poorly constrained but alter the outcome of competitive processes.

The second way of weighting the cohorts is a more determinstic method based on a strict rank-ordering of the cohorts by height, where all cohorts shorter than that cohorts whose cumulative (from the tallest cohort) rank-ordered crown area equals the area of the patch area are demoted to the lower canopy layer. This is derived from the original PPA algorithm described in Purves et al. 2008.

The process by which trees are moved between canopy layers is complex because 1) the crown area predicted for a cohort to lose may be larger than the total crown area of the cohort, which requires iterative solutions, and 2) on some occasions (e.g. after fire, or if the parameter which sets the disturbed area as a function of the fractional crown area of canopy tree mortality is less than one), the canopy may open up and require ‘promotion’ of cohorts from the understorey, and 3) canopy area may change due to the variations of canopy spread values (S_{c,patch,cl}, see the section below for details) when fractions of cohorts are demoted or promoted. Further details can be found in the code references in the footnote.

1.7.1. Horizontal Canopy Spread

Purves et al. 2008 estimated the ratio between canopy and stem diameter c_{p} as 0.1 m cm-1 for canopy trees in North American forests, but this estimate was made on trees in closed canopies, whose shape is subject to space competition from other individuals. Sapling trees have no constraints in their horizontal spatial structure, and as such, are more likely to display their leaves to full sunlight. Also, prior to canopy closure, light interception by leaves on the sides of the canopy is also higher than it would be in a closed canopy forest. If the ‘canopy spread’ parameter is constant for all trees, then we simulate high levels of self-shading for plants in unclosed canopies, which is arguably unrealistic and can lower the productivity of trees in areas of unclosed canopy (e.g. low productivity areas of boreal or semi-arid regions where LAI and canopy cover might naturally be low). We here interpret the degree of canopy spread, S_{c} as a function of how much tree crowns interfere with each other in space, or the total canopy area A_{canopy}. However A_{canopy} itself is a function of S_{c}, leading to a circularity. S_{c} is thus solved iteratively through time.

Each daily model step, A_{canopy} and the fraction of the gridcell occupied by tree crowns in the top canopy layer is calculated (based on S_{c} from the previous timestep):

(A_{f,1} = A_{canopy,1}/A_{site})

If A_{f,1} is greater than a threshold value A_{t}, S_{c} is increased by a small increment i, where i
= i_p \left\{ S_{c,\rm{max}} - S_{c,\rm{min}} \right\} (see bleow for definitions). The threshold A_{t} is, hypothetically, the canopy fraction at which light competition begins to impact on tree growth. This is less than 1.0 owing to the non-perfect spatial spacing of tree canopies. If A_{f,1} is greater than A_{t}, then S_{c} is reduced by an increment i, to reduce the spatial extent of the canopy, thus.

S_{c,t+1} = \left\{ \begin{array}{ll}
S_{c,t} + i& \textrm{for $A_{f,cl} < A_{t}$}\\
&\\
S_{c,t} - i& \textrm{for $A_{f,cl} > A_{t}$}\\
\end{array} \right.

The values of S_{c} are bounded to upper and lower limits. The lower limit corresponds to the observed canopy spread parameter for canopy trees S_{c,min} and the upper limit corresponds to the largest canopy extent S_{c,max}

S_{c} = \left\{ \begin{array}{ll}
S_{c,min}& \textrm{for } S_{c}< S_{c,\rm{min}}\\
&\\
S_{c,max}& \textrm{for } S_{c} > S_{c,\rm{max}}\\
\end{array} \right.

This iterative scheme requires two additional parameters (i_p and A_{t}). i_p takes a value between 0 and 1 and affects the speed with which canopy spread, S_c changes. However, the model is relatively insensitive to the choice of either i_p or A_{t}.

1.7.2. Definition of Leaf and Stem Area Profile

Within each patch, the model defines and tracks cohorts of multiple plant functional types that exist either in the canopy or understorey. Light on the top leaf surface of each cohort in the canopy is the same, and the rate of decay through the canopy is also the same for each PFT. Therefore, we accumulate all the cohorts of a given PFT together for the sake of the radiation and photosynthesis calculations (to avoid separate calculations for every cohort).

Therefore, the leaf area index for each patch is defined as a three-dimensional array \mathit{lai}_{cl,ft,z} where C_l

is the canopy layer, ft is the functional type and z is the leaf layer within each canopy. This three-dimensional structure is the basis of the radiation and photosynthetic models. In addition to a leaf area profile matrix, we also define, for each patch, the area which is covered by leaves at each layer as \mathit{carea}_{cl,ft,z}.

Each plant cohort is already defined as a member of a single canopy layer and functional type. This means that to generate the x_{cl,ft,z} matrix, it only remains to divide the leaf area of each cohort into leaf layers. First, we determine how many leaf layers are occupied by a single cohort, by calculating the ‘tree LAI’ as the total leaf area of each cohort divided by its crown area (both in m2)

\mathit{tree}_{lai,coh} = \frac{C_{leaf,coh}\cdot\mathrm{sla}_{ft}}{A_{crown,coh}}

where \mathrm{sla}_{ft} is the specific leaf area in m2 KgC-1 and C_{leaf} is in KgC per plant.

Stem area index (SAI) is ratio of the total area of all woody stems on a plant to the area of ground covered by the plant. During winter in deciduous areas, the extra absorption by woody stems can have a significant impact on the surface energy budget. However, in previous big leaf versions of the CLM, computing the circumstances under which stem area was visible in the absence of leaves was difficult and the algorithm was largely heuristic as a result. Given the multi-layer canopy introduced for FATES, we can determine the leaves in the higher canopy layers will likely shade stem area in the lower layers when leaves are on, and therefore stem area index can be calculated as a function of woody biomass directly.

Literature on stem area index is particularly poor, as it’s estimation is complex and not particularly amenable to the use of, for example, assumptions of random distribution in space that are typically used to calculate leaf area from light interception. Kucharik et al. 1998 estimated that SAI visible from an LAI2000 sensor was around 0.5 m2 m-2. Low et al. 2001 estimate that the wood area index for Ponderosa Pine forest is 0.27-0.33. The existing CLM(CN) algorithm sets the minimum SAI at 0.25 to match MODIS observations, but then allows SAI to rise as a function of the LAI lost, meaning than in some places, predicted SAI can reach value of 8 or more. Clearly, greater scientific input on this quantity is badly needed. Here we determine that SAI is a linear function of woody biomass, to at very least provide a mechanistic link between the existence of wood and radiation absorbed by it. The non-linearity between how much woody area exists and how much radiation is absorbed is provided by the radiation absorption algorithm. Specifically, the SAI of an individual cohort (\mathrm{tree}_{sai,coh}, m2 m-2) is calculated as follows,

\mathrm{tree}_{sai,coh} = k_{sai}\cdot C_{struc,coh} ,

where k_{sai} is the coefficient linking structural biomass to SAI. The number of occupied leaf layers for cohort coh (n_{z,coh}) is then equal to the rounded up integer value of the tree SAI ({tree}_{sai,coh}) and LAI ({tree}_{lai,coh}) divided by the layer thickness (i.e., the resolution of the canopy layer model, in units of vegetation index (lai+sai) with a default value of 1.0, \delta _{vai} ),

n_{z,coh} = {\frac{\mathrm{tree}_{lai,coh}+\mathrm{tree}_{sai,coh}}{\delta_{vai}}}.

The fraction of each layer that is leaf (as opposed to stem) can then be calculated as

f_{leaf,coh} = \frac{\mathrm{tree}_{lai,coh}}{\mathrm{tree}_{sai,coh}+\mathrm{tree}_{lai,coh}}.

Finally, the leaf area in each leaf layer pertaining to this cohort is thus

\mathit{lai}_{z,coh}  = \left\{ \begin{array}{ll}
 \delta_{vai} \cdot f_{leaf,coh} \frac{A_{canopy,coh}}{A_{canopy,patch}}& \textrm{for $i=1,..., i=n_{z,coh}-1$}\\
&\\
 \delta_{vai} \cdot f_{leaf,coh} \frac{A_{canopy,coh}}{A_{canopy,patch}}\cdot r_{vai}& \textrm{for $i=n_{z,coh}$}\\
\end{array} \right.

and the stem area index is

\mathit{sai}_{z,coh}  = \left\{ \begin{array}{ll}
 \delta_{vai} \cdot (1-f_{leaf,coh})\frac{A_{canopy,coh}}{A_{canopy,patch}}& \textrm{for $i=1,..., i=n_{z,coh}-1$}\\
&\\
 \delta_{vai} \cdot (1-f_{leaf,coh}) \frac{A_{canopy,coh}}{A_{canopy,patch}}\cdot r_{vai}& \textrm{for $i=n_{z,coh}$}\\
\end{array} \right.

where r_{vai} is the remainder of the canopy that is below the last full leaf layer

r_{vai} =(\mathrm{tree}_{lai,coh} + \mathrm{tree}_{sai,coh}) - (\delta _{vai} \cdot (n_{z,coh} -1)).

A_{canopy,patch} is the total canopy area occupied by plants in a given patch (m:math:^{2}) and is calculated as follows,

A_{canopy,patch} = \textrm{min}\left( \sum_{coh=1}^{coh = ncoh}A_{canopy,coh}, A_{patch}  \right).

The canopy is conceived as a cylinder, although this assumption could be altered given sufficient evidence that canopy shape was an important determinant of competitive outcomes, and the area of ground covered by each leaf layer is the same through the cohort canopy. With the calculated SAI and LAI, we are able to calculate the complete canopy profile. Specifically, the relative canopy area for the cohort {coh} is calculated as

\mathit{area}_{1:nz,coh}  =  \frac{A_{crown,coh}}{A_{canopy,patch}}.

The total occupied canopy area for each canopy layer (cl), plant functional type (ft) and leaf layer (z) bin is thus

\mathit{c}_{area,cl,ft,z} = \sum_{coh=1}^{coh=ncoh} area_{1:nz,coh}

where ft_{coh}=ft and cl_{coh} = cl.

All of these quantities are summed across cohorts to give the complete leaf and stem area profiles,

\mathit{lai} _{cl,ft,z} = \sum_{coh=1}^{coh=ncoh} \mathit{lai}_{z,coh}

\mathit{sai}_{cl,ft,z} = \sum_{coh=1}^{coh=ncoh} \mathit{sai}_{z,coh}

1.7.3. Burial of leaf area by snow

The calculations above all pertain to the total leaf and stem area indices which charecterize the vegetation structure. In addition, the model must know when the vegetation is covered by snow, and by how much, so that the albedo and energy balance calculations can be adjusted accordingly. Therefore, we calculated a ‘total’ and ‘exposed’ lai and sai profile using a representation of the bottom and top canopy heights, and the depth of the average snow pack. For each leaf layer z of each cohort, we calculate an ‘exposed fraction f_{exp,z} via consideration of the top and bottom heights of that layer h_{top,z} and h_{bot,z} (m),

\begin{array}{ll}
h_{top,z} = h_{coh} - h_{coh}\cdot f_{crown,ft}\cdot\frac{z}{n_{z,coh}}& \\
&\\
h_{bot,z} = h_{coh} - h_{coh}\cdot f_{crown,ft}\cdot\frac{z+1}{n_{z,coh}}&\\
\end{array}

where f_{crown,ft} is the plant functional type (ft) specific fraction of the cohort height that is occupied by the crown. Specifically, the ‘exposed fraction f_{exp,z} is calculated as follows,

f_{exp,z}\left\{ \begin{array}{ll}
= 1.0 &  h_{bot,z}> d_{snow}\\
&\\
= \frac{d_{snow} -h_{bot,z}}{h_{top,z}-h_{bot,z}}  & h_{top,z}> d_{snow}, h_{bot,z}< d_{snow}\\
&\\
= 0.0 & h_{top,z}< d_{snow}\\
\end{array} \right.

The resulting exposed (elai, esai) and total (tlai, tsai) leaf and stem area indicies are calculated as

\begin{array}{ll}
\mathit{elai} _{cl,ft,z} &= \mathit{lai} _{cl,ft,z} \cdot f_{exp,z}\\
\mathit{esai} _{cl,ft,z} &= \mathit{sai} _{cl,ft,z} \cdot f_{exp,z}\\
\mathit{tlai} _{cl,ft,z} &= \mathit{lai} _{cl,ft,z}\\
\mathit{tsai} _{cl,ft,z} &= \mathit{sai} _{cl,ft,z} \
\end{array} ,

and are used in the radiation interception and photosynthesis algorithms described later.

Parameter Symbol Parameter Name Units Notes Indexed by
\delta_{vai} Thickness of single canopy layer m2 m-2
C_e Competitive Exclusion Parameter none
c_{p
,min} Minimum canopy spread m2 cm-1
c_{p
,max} Competitive Exclusion Parameter m2 cm-1
i Incremental change in c_p m2 cm-1 y-1
A_t Threshold canopy closure none
f_{c
rown,ft} Crown fraction none   ft
k_{sai} Stem area per unit woody biomass m2 KgC-1

1.8. Radiation Transfer

1.8.1. Fundamental Radiation Transfer Theory

The first interaction of the land surface with the properties of vegetation concerns the partitioning of energy into that which is absorbed by vegetation, reflected back into the atmosphere, and absorbed by the ground surface. Older versions of the CLM have utilized a “two-stream” approximation Sellers 1985, Sellers et al. 1986 that provided an empirical solution for the radiation partitioning of a multi-layer canopy for two streams, of diffuse and direct light. However, implementation of the Ecosystem Demography model requires a) the adoption of an explicit multiple layer canopy b) the implementation of a multiple plant type canopy and c) the distinction of canopy and under-storey layers, in-between which the radiation streams are fully mixed. The radiation mixing between canopy layers is necessary as the position of different plants in the under-storey is not defined spatially or relative to the canopy trees above. In this new scheme, we thus implemented a one-dimensional scheme that traces the absorption, transmittance and reflectance of each canopy layer and the soil, iterating the upwards and downwards passes of radiation through the canopy until a pre-defined accuracy tolerance is reached. This approach is based on the work of Norman 1979.

Here we describe the basic theory of the radiation transfer model for the case of a single homogenous canopy, and in the next section we discuss how this is applied to the multi layer multi PFT canopy in the FATES implementation. The code considers the fractions of a single unit of incoming direct and a single unit of incoming diffuse light, that are absorbed at each layer of the canopy for a given solar angle (\alpha_{s}, radians). Direct radiation is extinguished through the canopy according to the coefficient k_{dir} that is calculated from the incoming solar angle and the dimensionless leaf angle distribution parameter (\chi) as

k_{dir} = g_{dir} / \sin(\alpha_s)\\

where

g_{dir} = \phi_1 + \phi_2 \cdot \sin(\alpha_s)\\

and

\begin{array} {l}
\phi_1 = 0.5 - 0.633\chi_{l} - 0.33\chi_l ^2\\
\phi_2 =0.877 (1 - 2\phi_1)\\

\end{array}

The leaf angle distribution is a descriptor of how leaf surfaces are arranged in space. Values approaching 1.0 indicate that (on average) the majority of leaves are horizontally arranged with respect to the ground. Values approaching -1.0 indicate that leaves are mostly vertically arranged, and a value of 0.0 denotes a canopy where leaf angle is random (a ‘spherical’ distribution).

According to Beer’s Law, the fraction of light that is transferred through a single layer of vegetation (leaves or stems) of thickness \delta_{vai}, without being intercepted by any surface, is

\mathit{tr}_{dir} = e^{-k_{dir}  \delta_{vai}}

and the incident direct radiation transmitted to each layer of the canopy (dir_{tr,z}) is thus calculated from the cumulative leaf area ( L_{above} ) shading each layer (z):

\mathit{dir}_{tr,z} = e^{-k_{dir}  L_{above,z}}

The fraction of the leaves f_{sun} that are exposed to direct light is also calculated from the decay coefficient k_{dir}.

\begin{array}{l}
f_{sun,z} = e^{-k_{dir}  L_{above,z}}\\
 \rm{and}
\\ f_{shade,z} = 1-f_{sun,z}
\end{array}

where f_{shade,z} is the fraction of leaves that are shaded from direct radiation and only receive diffuse light.

Diffuse radiation, by definition, enters the canopy from a spectrum of potential incident directions, therefore the un-intercepted transfer (tr_{dif}) through a leaf layer of thickness \delta_l is calculated as the mean of the transfer rate from each of 9 different incident light directions (\alpha_{s}) between 0 and 180 degrees to the horizontal.

\mathit{tr}_{dif} = \frac{1}{9} \sum\limits_{\alpha_s=5\pi/180}^{\alpha_s=85\pi/180} e^{-k_{dir,l} \delta_{vai}} \\ \\

tr_{dif}= \frac{1}{9} \pi \sum_{\alpha s=0}^{ \pi / 2}  \frac{e^{-gdir} \alpha_s}{\delta_{vai} \cdot \rm{sin}(\alpha_s) \rm{sin}(\alpha_s) \rm{cos}(\alpha_s)}

The fraction (1-tr_{dif}) of the diffuse radiation is intercepted by leaves as it passes through each leaf layer. Of this, some fraction is reflected by the leaf surfaces and some is transmitted through. The fractions of diffuse radiation reflected from (\mathit{refl}_{dif}) and transmitted though (\mathit{tran}_{dif}) each layer of leaves are thus, respectively

\begin{array}{l}
\mathit{refl_{dif}} = (1 - tr_{dif})  \rho_{l,ft}\\
\mathit{tran}_{dif} = (1 - tr_{dif})  \tau_{l,ft} + tr_{dif}
\end{array}

where \rho_{l,ft} and \tau_{l,ft} are the fractions of incident light reflected and transmitted by individual leaf surfaces.

Once we know the fractions of light that are transmitted and reflected by each leaf layer, we begin the process of distributing light through the canopy. Starting with the first leaf layer (z=1), where the incident downwards diffuse radiation (\mathit{dif}_{down}) is 1.0, we work downwards for n_z layers, calculating the radiation in the next layer down (z+1) as:

\mathit{dif}_{down,z+1} = \frac{\mathit{dif}_{down,z} \mathit{tran}_{dif} }    {1 - \mathit{r}_{z+1}  \mathit{refl}_{dif}}

Here, \mathit{dif}_{down,z} \mathit{tran}_{dif} calculates the fraction of incoming energy transmitted downwards onto layer z+1. This flux is then increased by the additional radiation r_z that is reflected upwards from further down in the canopy to layer z, and then is reflected back downwards according to the reflected fraction \mathit{refl_{dif}}. The more radiation in \mathit{r}_{z+1}  \mathit{refl}_{dif}, the smaller the denominator and the larger the downwards flux. r is also calculated sequentially, starting this time at the soil surface layer (where z = n_z+1)

r_{nz+1} = alb_s

where alb_s is the soil albedo characteristic. The upwards reflected fraction r_z for each leaf layer, moving upwards, is then Norman 1979

r_z  = \frac{r_{z+1}  \times \mathit{tran}_{dif}  ^{2} }{ (1 - r_{z+1}  \mathit{refl_{dif}}) + \mathit{refl_{dif}}}.

The corresponding upwards diffuse radiation flux is therefore the fraction of downwards radiation that is incident on a particular layer, multiplied by the fraction that is reflected from all the lower layers:

\mathit{dif}_{up,z} = r_z \mathit{dif}_{down,z+1}

Now we have initial conditions for the upwards and downwards diffuse fluxes, these must be modified to account for the fact that, on interception with leaves, direct radiation is transformed into diffuse radiation. In addition, the initial solutions to the upwards and downwards radiation only allow a single ‘bounce’ of radiation through the canopy, so some radiation which might be intercepted by leaves higher up is potentially lost. Therefore, the solution to this model is iterative. The iterative solution has upwards and a downwards components that calculate the upwards and downwards fluxes of total radiation at each leaf layer (rad_{dn, z} and rad_{up, z}) . The downwards component begins at the top canopy layer (z=1). Here we define the incoming solar diffuse and direct radiation (\it{solar}_{dir} and \it{solar}_{dir} respectively).

\begin{array}{l}
 \mathit{dif}_{dn,1} =  \it{solar}_{dif} \\
\mathit{rad}_{dn, z+1} = \mathit{dif}_{dn,z} \cdot  \mathit{tran}_{dif}  +\mathit{dif}_{up,z+1}   \cdot  \mathit{refl}_{dif}   + \mathit{solar}_{dir}  \cdot  dir_{tr,z}  (1- tr_{dir})  \tau_l.
\end{array}

The first term of the right-hand side deals with the diffuse radiation transmitted downwards, the second with the diffuse radiation travelling upwards, and the third with the direct radiation incoming at each layer (dir_{tr,z}) that is intercepted by leaves (1-  tr_{dir}) and then transmitted through through the leaf matrix as diffuse radiation (\tau_l). At the bottom of the canopy, the light reflected off the soil surface is calculated as

rad _{up, nz} =  \rm{\it{dif}}_{down,z}  \cdot  salb_{dif} +\it{solar}_{dir} \cdot dir_{tr,z} salb_{dir}.

The upwards propagation of the reflected radiation is then

rad_{up, z} = \mathit{dif}_{up,z+1} \cdot  \mathit{tran}_{dif}  +\mathit{dif}_{dn,z}   \cdot  \mathit{refl}_{dif}   + \it{solar}_{dir}  \cdot  dir_{tr,z}  (1- tr_{dir})  \rho_l.

Here the first two terms deal with the diffuse downwards and upwards fluxes, as before, and the third deals direct beam light that is intercepted by leaves and reflected upwards. These upwards and downwards fluxes are computed for multiple iterations, and at each iteration, rad_{up, z} and rad_{down, z} are compared to their values in the previous iteration. The iteration scheme stops once the differences between iterations for all layers is below a predefined tolerance factor, (set here at 10^{-4}). Subsequently, the fractions of absorbed direct (abs_{dir,z}) and diffuse (abs_{dif,z}) radiation for each leaf layer then

abs_{dir,z} = \it{solar}_{dir}   \cdot dir_{tr,z} \cdot (1- tr_{dir}) \cdot (1 - \rho_l-\tau_l)

abs_{dif,z} = (\mathit{dif}_{dn,z} +  \mathit{dif}_{up,z+1} ) \cdot (1 - tr_{dif}) \cdot (1 - \rho_l-\tau_l).

and, the radiation energy absorbed by the soil for the diffuse and direct streams is is calculated as

\it{abs}_{soil} = \mathit{dif}_{down,nz+1} \cdot (1 -  salb_{dif}) +\it{solar}_{dir}   \cdot dir_{tr,nz+1} \cdot (1-  salb_{dir}).

Canopy level albedo is denoted as the upwards flux from the top leaf layer

\it{alb}_{canopy}=  \frac{\mathit{dif}_{up,z+1}  }{  \it{solar}_{dir} + \it{solar}_{dif}}

and the division of absorbed energy into sunlit and shaded leaf fractions, (required by the photosynthesis calculations), is

abs_{sha,z} = abs_{dif,z} \cdot f_{sha}

abs_{sun,z} =  abs_{dif,z} \cdot f_{sun}+ abs_{dir,z}

1.8.2. Resolution of radiation transfer theory within the FATES canopy structure

The radiation transfer theory above, was described with reference to a single canopy of one plant functional type, for the sake of clarity of explanation. The FATES model, however, calculates radiative and photosynthetic fluxes for a more complex hierarchical structure within each patch/time-since-disturbance class, as described in the leaf area profile section. Firstly, we denote two or more canopy layers (denoted cl). The concept of a ‘canopy layer’ refers to the idea that plants are organized into discrete over and under-stories, as predicted by the Perfect Plasticity Approximation (Purves et al. 2008, Fisher et al. 2010). Within each canopy layer there potentially exist multiple cohorts of different plant functional types and heights. Within each canopy layer, cl, and functional type, ft, the model resolves numerous leaf layers z, and, for some processes, notably photosynthesis, each leaf layer is split into a fraction of sun and shade leaves, f_{sun} and f_{sha}, respectively.

The radiation scheme described in Section is solved explicitly for this structure, for both the visible and near-infrared wavebands, according to the following assumptions.

  • A canopy layer (cl) refers literally to the vertical layer within the canopy this cohort resides in. The top canopy layer has index 1. A closed canopy forest will therefore by definition have at least two layers, and perhaps more.
  • A leaf layer (z) refers to the discretization of the LAI within the canopy of a given plant functional type.
  • All PFTs in the same canopy layer have the same solar radiation incident on the top layer of the canopy
  • Light is transmitted through the canopy of each plant functional type independently
  • Between canopy layers, the light streams from different plant functional types are mixed, such that the (undefined) spatial location of plants in lower canopy layers does not impact the amount of light received.
  • Where understorey layers fill less area than the overstorey layers, radiation is directly transferred to the soil surface.
  • All these calculations pertain to a single patch, so we omit the patch subscript for simplicity in the following discussion.

Within this framework, the majority of the terms in the radiative transfer scheme are calculated with indices of cl, \it{ft} and z. In the following text, we revisit the simplified version of the radiation model described above, and explain how it is modified to account for the more complex canopy structure used by FATES.

Firstly, the light penetration functions, k_{dir} and g_{dir} are described as functions of \it{ft}, because the leaf angle distribution, \chi_l, is a pft-specific parameter. Thus, the diffuse irradiance transfer rate, tr_{dif} is also \it{ft} specific because g_{dir}, on which it depends, is a function of \chi_l.

The amount of direct light reaching each leaf layer is a function of the leaves existing above the layer in question. If a leaf layer ‘z’ is in the top canopy layer (the over-storey), it is only shaded by leaves of the same PFT so k_{dir} is unchanged from equation. If there is more than one canopy layer (cl_{max}>1), then the amount of direct light reaching the top leaf surfaces of the second/lower layer is the weighted average of the light attenuated by all the parallel tree canopies in the canopy layer above, thus.

dir_{tr(cl,:,1)} =\sum_{ft=1}^{npft}{(dir_{tr(cl,ft,z_{max})} \cdot c_{area(cl-1,ft,z_{max})})}

where \it{pft}_{wt} is the areal fraction of each canopy layer occupied by each functional type and z_{max} is the index of the bottom canopy layer of each pft in each canopy layer (the subscripts

cl and ft are implied but omitted from all z_{max} references to avoid additional complications)

Similarly, the sunlit fraction for a leaf layer ‘z’ in the second canopy layer (where cl > 1) is

f_{sun(cl,ft,z)} = W_{sun(cl)} \cdot e^{k_{dir(ft,laic,z)}}

where W_{sun,cl} is the weighted average sunlit fraction in the bottom layer of a given canopy layer.

W_{sun(cl)} = \sum_{ft=1}^{npft}{(f_{sun(cl-1,ft,zmax)} \cdot  c_{area(cl-1,ft,zmax)})}

Following through the sequence of equations for the simple single pft and canopy layer approach above, the \mathit{refl}_{dif} and \mathit{tran}_{dif} fluxes are also indexed by cl, \it{ft}, and z. The diffuse radiation reflectance ratio r_z is also calculated in a manner that homogenizes fluxes between canopy layers. For the canopy layer nearest the soil (cl = cl_{max}). For the top canopy layer (cl=1), a weighted average reflectance from the lower layers is used as the baseline, in lieu of the soil albedo. Thus:

r_{z(cl,:,1)} =  \sum_{ft=1}^{npft}{(r_{z(cl-1,ft,1)}   \it{pft}_{wt(cl-1,ft,1)})}

For the iterative flux resolution, the upwards and downwards fluxes are also averaged between canopy layers, thus where cl>1

rad_{dn(cl,ft,1)} = \sum_{ft=1}^{npft}{(rad_{dn(cl-1,ft,zmax)} \cdot  \it{pft}_{wt(cl-1,ft,zmax)})}

and where cl =1, and cl_{max}>1

rad_{up(cl,ft,zmax)} = \sum_{ft=1}^{npft}{(rad_{up(cl+1,ft,1)} \cdot  \it{pft}_{wt(cl+1,ft,1)})}

The remaining terms in the radiation calculations are all also indexed by cl, ft and z so that the fraction of absorbed radiation outputs are termed abs_{dir(cl,ft,z)} and abs_{dif(cl,ft,z)}. The sunlit and shaded absorption rates are therefore

abs_{sha(cl,ft,z)} = abs_{dif(cl,ft,z)}\cdot f_{sha(cl,ft,z)}

and

abs_{sun(cl,ft,z)} =  abs_{dif(cl,ft,z)} \cdot f_{sun(cl,ft,z)}+ abs_{dir(cl,ft,z)}

The albedo of the mixed pft canopy is calculated as the weighted average of the upwards radiation from the top leaf layer of each pft where cl=1:

\it{alb}_{canopy}=  \sum_{ft=1}^{npft}{\frac{\mathit{dif}_{up(1,ft,1)}    \it{pft}_{wt(1,ft,1)}} {\it{solar}_{dir} + \it{solar}_{dif}}}

The radiation absorbed by the soil after passing through through under-storey vegetation is:

\it{abs}_{soil}=  \sum_{ft=1}^{npft}{ \it{pft}_{wt(1,ft,1)}( \mathit{dif}_{down(nz+1)} (1 -  salb_{dif}) +\it{solar}_{dir}   dir_{tr(nz+1)}  (1-  salb_{dir}))}

to which is added the diffuse flux coming directly from the upper canopy and hitting no understorey vegetation.

\it{abs}_{soil}=  \it{abs}_{soil}+dif_{dn(2,1)}  (1-  \sum_{ft=1}^{npft}{\it{pft}_{wt(1,ft,1)}})  (1 -  salb_{dif})

and the direct flux coming directly from the upper canopy and hitting no understorey vegetation.

\it{abs}_{soil}=  \it{abs}_{soil}+\it{solar}_{dir} dir_{tr(2,1)}(1-  \sum_{ft=1}^{npft}{\it{pft}_{wt(1,ft,1)}})  (1 -  salb_{dir})

These changes to the radiation code are designed to be structurally flexible, and the scheme may be collapsed down to only include on canopy layer, functional type and pft for testing if necessary.

Parameter Symbol Parameter Name Units indexed by
\chi Leaf angle distribution parameter none ft
\rho_l Fraction of light reflected by leaf surface none ft
\tau_l Fraction of light transmitted by leaf surface none ft
alb_s Fraction of light reflected by soil none direct vs diffuse

1.9. Photosynthesis

1.9.1. Fundamental photosynthetic physiology theory

In this section we describe the physiological basis of the photosynthesis model before describing its application to the FATES canopy structure. This description in this section is largely repeated from the Oleson et al. CLM4.5 technical note but included here for comparison with its implementation in FATES. Photosynthesis in C3 plants is based on the model of Farquhar 1980 as modified by Collatz et al. (1991). Photosynthetic assimilation in C4 plants is based on the model of Collatz et al. (1991). In both models, leaf photosynthesis, \textrm{gpp} (\mumol CO_2 m^{-2} s^{-1}) is calculated as the minimum of three potentially limiting fluxes, described below:

\textrm{gpp} = \rm{min}(w_{j}, w_{c},w_{p}).

The RuBP carboxylase (Rubisco) limited rate of carboxylation w_{c} (\mumol CO_{2} m^{-2} s^{-1}) is determined as

w_{c}=  \left\{ \begin{array}{ll}
\frac{V_{c,max}(c_{i} - \Gamma_*)}{ci+K_{c}(1+o_{i}/K_{o})} & \textrm{for $C_{3}$ plants}\\
&\\
V_{c,max}& \textrm{for $C_{4}$ plants}\\
\end{array} \right.
c_{i}-\Gamma_*\ge 0

where c_{i} is the internal leaf CO_{2} partial pressure (Pa) and o_i (0.209P_{atm}) is the O_{2} partial pressure (Pa). K_{c} and K_{o} are the Michaelis-Menten constants (Pa) for CO_{2} and O_{2}. These vary with vegetation temperature T_v (^{o}C) according to an Arrhenious function described in Oleson et al. 2013. V_{c,max} is the leaf layer photosynthetic capacity (\mu mol CO_2 m^{-2} s^{-1}).

The maximum rate of carboxylation allowed by the capacity to regenerate RuBP (i.e., the light-limited rate) w_{j} (\mumol CO_2 m^{-2} s^{-1}) is

w_j=  \left\{ \begin{array}{ll}
\frac{J(c_i - \Gamma_*)}{4ci+8\Gamma_*} & \textrm{for C$_3$ plants}\\
&\\
4.6\phi\alpha & \textrm{for C$_4$ plants}\\
\end{array} \right.
c_i-\Gamma_*\ge 0

To find J, the electron transport rate (\mu mol CO_2 m^{-2} s^{-1}), we solve the following quadratic term and take its smaller root,

\Theta_{psII}J^{2}-(I_{psII} +J_{max})J+I_{psII}J_{max} =0

where J_{max} is the maximum potential rate of electron transport (\mumol m_{-2} s^{-1}), I_{PSII} is the is the light utilized in electron transport by photosystem II (\mumol m_{-2} s^{-1}) and \Theta_{PSII} is is curvature parameter. I_{PSII} is determined as

I_{PSII} =0.5 \Phi_{PSII}(4.6\phi)

where \phi is the absorbed photosynthetically active radiation (Wm:math:^{-2}) for either sunlit or shaded leaves (abs_{sun} and abs_{sha}). \phi is converted to photosynthetic photon flux assuming 4.6 \mumol photons per joule. Parameter values are \Phi_{PSII} = 0.7 for C3 and \Phi_{PSII} = 0.85 for C4 plants.

The export limited rate of carboxylation for C3 plants and the PEP carboxylase limited rate of carboxylation for C4 plants w_e (also in \mumol CO_2 m^{-2} s^{-1}) is

w_e=  \left\{ \begin{array}{ll}
3 T_{p,0} & \textrm{for $C_3$ plants}\\
&\\
k_{p} \frac{c_i}{P_{atm}}& \textrm{for $C_4$ plants}.\\
\end{array} \right.

T_{p} is the triose-phosphate limited rate of photosynthesis, which is equal to 0.167 V_{c,max0}. k_{p} is the initial slope of C4 CO_{2} response curve. The Michaelis-Menten constants K_{c} and K_{o} are modeled as follows,

K_{c} = K_{c,25}(a_{kc})^{\frac{T_v-25}{10}},

K_{o} = K_{o,25}(a_{ko})^{\frac{T_v-25}{10}},

where K_{c,25} = 30.0 and K_{o,25} = 30000.0 are values (Pa) at 25 ^{o}C, and a_{kc} = 2.1 and a_{ko} =1.2 are the relative changes in K_{c,25} and K_{o,25} respectively, for a 10^{o}C change in temperature. The CO_{2} compensation point \Gamma_{*} (Pa) is

\Gamma_* = \frac{1}{2} \frac{K_c}{K_o}0.21o_i

where the term 0.21 represents the ratio of maximum rates of oxygenation to carboxylation, which is virtually constant with temperature Farquhar, 1980.

1.9.2. Resolution of the photosynthesis theory within the FATES canopy structure.

The photosynthesis scheme is modified from the CLM4.5 model to give estimates of photosynthesis, respiration and stomatal conductance for a three dimenstional matrix indexed by canopy level (C_l), plant functional type (ft) and leaf layer (z). We conduct the photosynthesis calculations at each layer for both sunlit and shaded leaves. Thus, the model also generates estimates of w_{c},w_{j} and w_{e} indexed in the same three dimensional matrix. In this implementation, some properties (stomatal conductance parameters, top-of-canopy photosynthetic capacity) vary with plant functional type, and some vary with both functional type and canopy depth (absorbed photosynthetically active radiation, nitrogen-based variation in photosynthetic properties). The remaining drivers of photosynthesis (P_{atm}, K_c, o_i, K_o, temperature, atmospheric CO_2) remain the same throughout the canopy. The rate of gross photosynthesis (gpp_{cl,ft,z})is the smoothed minimum of the three potentially limiting processes (carboxylation, electron transport, export limitation), but calculated independently for each leaf layer:

\textrm{gpp}_{cl,ft,z} = \rm{min}(w_{c,cl,ft,z},w_{j,cl,ft,z},w_{e,cl,ft,z}).

For w_{c,cl,ft,z},, we use

w_{c,cl,ft,z}=  \left\{ \begin{array}{ll}
\frac{V_{c,max,cl,ft,z}(c_{i,cl,ft,z}- \Gamma_*)}{c_{i,cl,ft,z}+K_c(1+o_i/K_o)} & \textrm{for $C_3$ plants}\\
&\\
V_{c,max,cl,ft,z}& \textrm{for $C_4$ plants}\\
\end{array} \right.
c_{i,cl,ft,z}-\Gamma_*\ge 0

where V_{c,max} now varies with PFT, canopy depth and layer (see below). Internal leaf CO_{2} (c_{i,cl,ft,z}) is tracked seperately for each leaf layer. For the light limited rate w_j, we use

w_j=  \left\{ \begin{array}{ll}
\frac{J(c_i - \Gamma_*)4.6\phi\alpha}{4ci+8\Gamma_*} & \textrm{for C$_3$ plants}\\
&\\
4.6\phi\alpha & \textrm{for C$_4$ plants}\\
\end{array} \right.

where J is calculated as above but based on the absorbed photosynthetically active radiation( \phi_{cl,ft,z}) for either sunlit or shaded leaves in Wm^{-2}. Specifically,

\phi_{cl,ft,z}=  \left\{ \begin{array}{ll}
abs_{sun,cl,ft,z}& \textrm{for sunlit leaves}\\
&\\
abs_{sha,cl,ft,z}& \textrm{for shaded leaves}\\
\end{array} \right.

The export limited rate of carboxylation for C3 plants and the PEP carboxylase limited rate of carboxylation for C4 plants w_c (also in \mumol CO_2 m^{-2} s^{-1}) is calculated in a similar fashion,

w_{e,cl,ft,z}=  \left\{ \begin{array}{ll}
0.5V_{c,max,cl,ft,z} & \textrm{for $C_3$ plants}\\
&\\
4000 V_{c,max,cl,ft,z} \frac{c_{i,cl,ft,z}}{P_{atm}}& \textrm{for $C_4$ plants}.\\
\end{array} \right.

1.9.3. Variation in plant physiology with canopy depth

Both V_{c,max} and J_{max} vary with vertical depth in the canopy on account of the well-documented reduction in canopy nitrogen through the leaf profile, see Bonan et al. 2012 for details). Thus, both V_{c,max} and J_{max} are indexed by by C_l, ft and z according to the nitrogen decay coefficient K_n and the amount of vegetation area shading each leaf layer V_{above},

\begin{array}{ll}
V_{c,max,cl,ft,z} & = V_{c,max0,ft} e^{-K_{n,ft}V_{above,cl,ft,z}},\\
J_{max,cl,ft,z} & = J_{max0,ft} e^{-K_{n,ft}V_{above,cl,ft,z}},\\
\end{array}

where V_{c,max,0} and J_{max,0} are the top-of-canopy photosynthetic rates. V_{above} is the sum of exposed leaf area index (\textrm{elai}_{cl,ft,z}) and the exposed stem area index (\textrm{esai}_{cl,ft,z})( m^{2} m^{-2} ). Namely,

V_{cl,ft,z} = \textrm{elai}_{cl,ft,z} + \textrm{esai}_{cl,ft,z}.

The vegetation index shading a particular leaf layer in the top canopy layer is equal to

\begin{array}{ll}
V_{above,cl,ft,z}= \sum_{1}^{z} V_{cl,ft,z} & \textrm{for $cl= 1$. }
\end{array}

For lower canopy layers, the weighted average vegetation index of the canopy layer above (V_{canopy}) is added to this within-canopy shading. Thus,

\begin{array}{ll}
V_{above,cl,ft,z}=  \sum_{1}^{z}  V_{cl,ft,z} + V_{canopy,cl-1} & \textrm{for $cl >1$, }\\
\end{array}

where V_{canopy} is calculated as

V_{canopy,cl} =  \sum_{ft=1}^{\emph{npft}} {\sum_{z=1}^{nz(ft)} (V_{cl,ft,z} \cdot  \it{pft}_{wt,cl,ft,1}).}

K_{n} is the coefficient of nitrogen decay with canopy depth. The value of this parameter is taken from the work of Lloyd et al. 2010 who determined, from 204 vertical profiles of leaf traits, that the decay rate of N through canopies of tropical rainforests was a function of the V_{cmax} at the top of the canopy. They obtain the following term to predict K_{n},

K_{n,ft} = e^{0.00963 V_{c,max0,ft} - 2.43},

where V_{cmax} is again in \mumol CO_2 m^{-2} s^{-1}.

1.9.4. Water Stress on gas exchange

The top of canopy leaf photosynthetic capacity, V_{c,max0}, is also adjusted for the availability of water to plants as

V_{c,max0,25} = V_{c,max0,25}  \beta_{sw},

where the adjusting factor \beta_{sw} ranges from one when the soil is wet to zero when the soil is dry. It depends on the soil water potential of each soil layer, the root distribution of the plant functional type, and a plant-dependent response to soil water stress,

\beta_{sw} = \sum_{j=1}^{nj}w_{j}r_{j},

where w_{j} is a plant wilting factor for layer j and r_{j} is the fraction of roots in layer j.The plant wilting factor w_{j} is

w_{j}=  \left\{ \begin{array}{ll}
\frac{\psi_c-\psi_{j}}{\psi_c - \psi_o} (\frac{\theta_{sat,j} - \theta_{ice,j}}{\theta_{sat,j}})& \textrm{for $T_i >$-2C}\\
&\\
0 & \textrm{for $T_{j} \ge$-2C}\\
\end{array} \right.

where \psi_{i} is the soil water matric potential (mm) and \psi_{c} and \psi_{o} are the soil water potential (mm) when stomata are fully closed or fully open, respectively. The term in brackets scales w_{i} the ratio of the effective porosity (after accounting for the ice fraction) relative to the total porosity. w_{i} = 0 when the temperature of the soil layer (T_{i} ) is below some threshold (-2:math:^{o}C) or when there is no liquid water in the soil layer (\theta_{liq,i} \le 0). For more details on the calculation of soil matric potential, see the CLM4.5 technical note.

1.9.4.1. Variation of water stress and water uptake within tiles

The remaining drivers of the photosynthesis model remain constant (atmospheric CO_2 and O^2 and canopy temperature) throughout the canopy, except for the water stress index \beta_{sw}. \beta_{sw} must be indexed by ft, because plants of differing functional types have the capacity to have varying root depth, and thus access different soil moisture profile and experience differing stress functions. Thus, the water stress function applied to gas exchange calculation is now calculated as

\beta_{sw,ft} = \sum_{j=1}^{nj}w_{j,ft} r_{j,ft},

where w_{j} is the water stress at each soil layer j and r_{j,ft} is the root fraction of each PFT’s root mass in layer j. Note that this alteration of the \beta_{sw} parameter also necessitates recalculation of the vertical water extraction profiles. In the original model, the fraction of extraction from each layer (r_{e,j,patch}) is the product of a single root distribution, because each patch only has one plant functional type. In FATES, we need to calculate a new weighted patch effective rooting depth profile r_{e,j,patch} as the weighted average of the functional-type level stress functions and their relative contributions to canopy conductance. Thus for each layer j, the extraction fraction is summed over all PFTs as

r_{e,j,patch} =  \sum_{ft=1}^{ft=npft} \frac{w_{j,ft}}{\sum_{j=1}^{=nj} w_{j,ft} }\frac{G_{s,ft}}{G_{s,canopy}},

where nj is the number of soil layers, G_{s,canopy}is the total canopy (see section 9 for details) and G_{s,ft} is the canopy conductance for plant functional type ft,

G_{s,ft}= \sum_{1}w_{ncoh,ft} {gs_{can,coh} n_{coh} }.

1.9.5. Aggregation of assimilated carbon into cohorts

The derivation of photosynthetic rates per leaf layer, as above, give us the estimated rate of assimilation for a unit area of leaf at a given point in the canopy in \mumol CO_2 m^{-2} s_{-1}. To allow the integration of these rates into fluxes per individual tree, or cohort of trees (gCO:math:_2 tree^{-1} s^{-1}), they must be multiplied by the amount of leaf area placed in each layer by each cohort. Each cohort is described by a single functional type, ft and canopy layer C_l flag, so the problem is constrained to integrating these fluxes through the vertical profile (z).

We fist make a weighted average of photosynthesis rates from sun (\textrm{gpp}_{sun}, \mumol CO_2 m^{-2} s^{-1}) and shade leaves ( \textrm{gpp}_{shade}, \mumol CO_2 m^{-2} s^{-1}) as

\textrm{gpp}_{cl,ft,z} =\textrm{gpp}_{sun,cl,ft,z} f_{sun,cl,ft,z}+ \textrm{gpp}_{sha,cl,ft,z}(1-f_{sun,cl,ft,z}).

The assimilation per leaf layer is then accumulated across all the leaf layers in a given cohort (coh) to give the cohort-specific gross primary productivity (\mathit{GPP}_{coh}),

\textit{GPP}_{coh} = 12\times 10^{-9}\sum_{z=1}^{nz(coh)}gpp_{cl,ft,z} A_{crown,coh} \textrm{elai}_{cl,ft,z}

The \textrm{elai}_{l,cl,ft,z} is the exposed leaf area which is present in each leaf layer in m^{2} m^{-2}. (For all the leaf layers that are completely occupied by a cohort, this is the same as the leaf fraction of \delta_{vai}). The fluxes are converted from \mumol into mol and then multiplied by 12 (the molecular weight of carbon) to give units for GPP_{coh} of KgC cohort^{-1} s^{-1}. These are integrated for each timestep to give KgC cohort^{-1} day^{-1}

Parameter Symbol Parameter Name Units indexed by
V_{c,max
0} Maximum carboxylation capacity \mu mol CO _2 m ^{-2} s ^{-1} ft
r_b Base Rate of Respiration gC gN^{-1
} s^{-1})
q_{10} Temp. Response of stem and root respiration
R_{cn,le
af,ft} CN ratio of leaf matter gC/gN ft
R_{cn,ro
ot,ft} CN ratio of root matter gC/gN ft
f_{gr} Growth Respiration Fraction none
\psi_c Water content when stomata close Pa ft
\psi_o Water content above which stomata are open Pa ft

1.10. Plant respiration

Plant respiration per individual R_{plant,coh} (KgC individual ^{-1} s^{-1}) is the sum of two terms, growth and maintenance respiration R_{g,coh} and R_{m,coh}

R_{plant} = R_{g,coh}+ R_{m,coh}

Maintenance respiration is the sum of the respiration terms from four different plant tissues, leaf, R_{m,leaf,coh}, fine root R_{m,froot,coh}, coarse root R_{m,croot,coh}and stem R_{m,stem,coh}, all also in (KgC individual ^{-1} s^{-1}) .

R_{m,coh} = R_{m,leaf,coh}+ R_{m,froot,coh}+R_{m,croot,coh}+R_{m,stem,coh}

To calculate canopy leaf respiration, which varies through we canopy, we first determine the top-of-canopy leaf respiration rate (r_{m,leaf,ft,0}, gC s^{-1} m^{-2}) is calculated from a base rate of respiration per unit leaf nitrogen derived from Ryan et al. 1991. The base rate for leaf respiration (r_{b}) is 2.525 gC/gN s^{-1},

r_{m,leaf,ft,0} = r_{b} N_{a,ft}(1.5^{(25-20)/10})

where r_b is the base rate of metabolism (2.525 x 10^6 gC/gN s^{-1}. This base rate is adjusted assuming a Q_{10} of 1.5 to scale from the baseline of 20C to the CLM default base rate temperature of 25C. For use in the calculations of net photosynthesis and stomatal conductance, leaf respiration is converted from gC s^{-1} m^{-2}, into \mumol CO_2 m^{-2} s^{-1} (/12\cdot 10^{-6}).

This top-of-canopy flux is scaled to account for variation in N_a through the vertical canopy, in the same manner as the V_{c,max} values are scaled using V_{above}.

r_{leaf,cl,ft,z}  = r_{m,leaf,ft,0} e^{-K_{n,ft}V_{above,cl,ft,z}}\beta_{ft}f(t)

Leaf respiration is also adjusted such that it is reduced by drought stress, \beta_{ft}, and canopy temperature, f(t_{veg}). For details of the temperature functions affecting leaf respiration see the CLM4 technical note, Section 8, Equations 8.13 and 8.14. The adjusted leaf level fluxes are scaled to individual-level (gC individual ^{-1} s^{-1}) in the same fashion as the \rm{GPP}_{coh} calculations

\rm{R}_{m,leaf,coh} = 12\times 10^{-9}\sum_{z=1}^{nz(coh)}r_{leaf,cl,ft,z} A_{crown} \textrm{elai}_{cl,ft,z}

The stem and the coarse-root respiration terms are derived using the same base rate of respiration per unit of tissue Nitrogen.

R_{m,croot,coh} =  10^{-3}r_b t_c \beta_{ft} N_{\rm{livecroot,coh}}

R_{m,stem,coh} =   10^{-3}r_b t_c \beta_{ft} N_{\rm{stem,coh}}

Here, t_c is a temperature relationship based on a q_{10} value of 1.5, where t_v is the vegetation temperature. We use a base rate of 20 here as, again, this is the baseline temperature used by Ryan et al. 1991. The 10^{-3} converts from gC invididual^{-1} s^{-1} to KgC invididual^{-1} s^{-1}

t_c=q_{10}^{(t_{v} - 20)/10}

The tissue N contents for live sapwood are derived from the leaf CN ratios, and for fine roots from the root CN ratio as:

N_{\rm{stem,coh}}  = \frac{B_{\rm{sapwood,coh}}}{ R_{cn,leaf,ft}}

and

N_{\rm{livecroot,coh}}  = \frac{ B_{\rm{root,coh}}w_{frac,ft}}{R_{cn,root,ft}}

where B_{\rm{sapwood,coh}} and B_{\rm{root,coh}} are the biomass pools of sapwood and live root biomass respectively (KgC individual) and w_{frac,ft} is the fraction of coarse root tissue in the root pool (0.5 for woody plants, 0.0 for grasses and crops). We assume here that stem CN ratio is the same as the leaf C:N ratio, for simplicity. The final maintenance respiration term is derived from the fine root respiration, which accounts for gradients of temperature in the soil profile and thus calculated for each soil layer j as follows:

R_{m,froot,j } = \frac{(1 - w_{frac,ft})B_{\rm{root,coh}}b_r\beta_{ft}}{10^3R_{cn,leaf,ft}}   \sum_{j=1}^{nj}t_{c,soi,j} r_{i,ft,j}

t_{c,soi} is a function of soil temperature in layer j that has the same form as that for stem respiration, but uses vertically resolved soil temperature instead of canopy temperature. In the CLM4.5, only coarse and not fine root respriation varies as a function of soil depth, and we maintain this assumption here, although it may be altered in later versions.

The source of maintenance respiration is the plant’s carbon storage pool, which is updated daily. For plants that are in long-term negative carbon balance, FATES assumes a tradoff between reduced maintenance respiration expenditures and increased carbon-starvation mortality (see section ‘Plant Mortality’). This reduction of maintenance respiration during carbon starvation is consistent with observations of trees under acute carbon stress (Sevanto et al., 2014). Because the physiologic basis and form of this process is poorly constrained, we use heuristic functions here to define these processes. First, we define a target carbon storage pool (\grave{C}_{store,coh}):

\grave{C}_{store,coh} = r_{store} \grave{C}_{leaf,coh}

where r_{store} is a pft-specific parameter that linearly relates the target storage pool to the target leaf biomass \grave{C}_{leaf,coh}. If a given plant is unable to achieve its target carbon storage because of having a negative NPP at any given time, then its actual storage pool C_{store,coh} will drop below the target storage pool \grave{C}_{store,coh}. Then FATES sets the fractional rate of maintenance respiration (R) on the ratio of C_{store,coh} to \grave{C}_{leaf,coh}:

R = \left\{ \begin{array}{ll}
(1-q^{(C_{store,coh}/\grave{C}_{leaf,coh})})/(1-q)& C_{store,coh}<\grave{C}_{leaf,coh}\\
&\\
1& C_{store,coh} >= \grave{C}_{leaf,coh}\\
\end{array} \right.

where q is a parameter that governs the curvature of the respiration reduction function. This parameter is specific to a given PFT.

The growth respiration, R_{g,coh} is a fixed fraction f_{gr} of the carbon remaining after maintenance respiration has occurred.

R_{g,coh}=\textrm{max}(0,GPP_{g,coh} - \it R\rm_{m,coh})f_{gr}

Parameter Symbol Parameter Name Units indexed by
-K_{n,ft
} Rate of reduction of N through the canopy none
r_b Base Rate of Respiration gC gN^{-1
} s^{-1})
q_{10} Temp. Response of stem and root respiration
R_{cn,le
af,ft} CN ratio of leaf matter gC/gN ft
R_{cn,ro
ot,ft} CN ratio of root matter gC/gN ft
f_{gr} Growth Respiration Fraction none ft
q Low-Storage Maintenance Respiration Reduction Param. none ft

1.11. Stomatal Conductance

1.11.1. Fundamental stomatal conductance theory

Within FATES, leaf-level stomatal conductance is representated by two main approaches. The first calculates stomatal conductance (1/resistance) using the Ball-Berry model as implemented in CLM4.5 (http://www.cesm.ucar.edu/models/cesm1.2/clm/CLM45_Tech_Note.pdf) and described by Collatz et al. (1991) and Sellers et al. 1996. The model relates stomatal conductance (i.e., the inverse of resistance) to net leaf photosynthesis, scaled by the relative humidity at the leaf surfaceand the CO_2 concentration at the leaf surface. The primary difference between the CLM implementation and that used by Collatz et al. (1991) and Sellers et al. (1996) is that they used net photosynthesis (i.e., leaf photosynthesis minus leaf respiration) instead of gross photosynthesis. As implemented here, stomatal conductance equals the minimum conductance (b) when gross photosynthesis (A) is zero. Leaf stomatal conductance is

\frac{1}{r_{s}} = m_{ft} \frac{A}{c_s}\frac{e_s}{e_i}P_{atm}+b_{ft} \beta_{sw}

where r_{s} is leaf stomatal resistance (s m^2 leaf area \mumol H_{2}O^{-1}), b_{ft} in units of \mumol H_{2}O m^{-2} leaf area s^{-1} is a plant functional type dependent parameter equivalent to g_{0} in the Ball-Berry model literature. This parameter is also scaled by the water stress index \beta_{sw}. Similarly, m_{ft} is the slope of the relationship (i.e. stomatal slope, or the g_{1} term in the stomatal literature) between stomatal conductance and the stomatal index, comprised of the leaf assimilation rate, A (\mumol CO_2 m^{-2} leaf area s^{-1}), c_s is the CO_2 partial pressure at the leaf surface (Pa), e_s is the vapor pressure at the leaf surface (Pa), e_i is the saturation vapor pressure (Pa) inside the leaf at the vegetation temperature T_{v} (K), and b_{ft} is the conductace (\mumolH_{2}O m^{-2} leaf area s^{-1}) when A = 0.

The second (default) representation of stomatal conductance in FATES follows the Unified Stomatal Optimization (USO) theory, otherwise known as the Medlyn model of stomatal conductance (Medlyn et al. 2011). The Medlyn model calculates stomatal conductance (i.e., the inverse of resistance) based on net leaf photosynthesis, the vapor pressure deficit, and the CO2 concentration at the leaf surface. Leaf stomatal resistance is calculated as:

\frac{1}{r_{s}} = g_{s} = b_{ft} \beta_{sw}+1.6(1+\frac{m_{ft}}{\sqrt{D_{s}}})\frac{A_{n}}{C_{s}/{P_{atm}}}

Parameter Symbol Parameter Name Units indexed by
r_{s} Leaf stomatal resistance s m^{2} leaf area \mumol H_{2}O^{-1}
g_{s} Leaf stomatal conductance \mumol H_{2}O m^{2} leaf area s^{-1}
b_{ft} Minimum stomatal conductance or the cuticular conductance \mumol H_{2}O m^{2} leaf area s^{-1} ft
\beta_{sw} Soil water stress factor none
D_{s} Vapor pressure deficit at the leaf surface kPa
m_{ft} Stomatal slope kPa^{0.5} ft
A_{n} Leaf net photosynthesis \mumol CO_{2} m^{-2} leaf area s^{-1}
C_{s} CO_{2} partial pressure at the leaf surface Pa
P_{atm} Atmospheric pressure Pa

In both models leaf resistance is converted from units of s m^2 \mumolH_{2}O^{-1} to s m^{-1} as: 1 s m^{-1} = 1\times 10^{-9}R_{\rm{gas}} \theta_{\rm{atm}}P_{\rm{atm}} (\mumol^{-1} m^{2} s), where R_{gas} is the universal gas constant (J K^{-1} kmol^{-1}) and \theta_{atm} is the atmospheric potential temperature (K).

Both b_{ft} and m_{ft} are PFT-specific parameters. The default values for the Ball-Berry and Medlyn stomatal conductance model representations are provide below:

PFT Name Ball-Berry m_{ft} (unitless) Medlyn m_{ft} (kPa^{0.5})
Broadleaf evergreen tropical tree 8 4.1
Needleleaf evergreen extratropical tree 8 2.3
Needleleaf colddecid extratropical tree 8 2.3
Broadleaf evergreen extratropical tree 8 4.1
Broadleaf hydrodecid tropical tree 8 4.4
Broadleaf colddecid extratropical tree 8 4.4
Broadleaf evergreen extratropical shrub 8 4.7
Broadleaf hydrodecid extratropical shrub 8 4.7
Broadleaf colddecid extratropical shrub 8 4.7
Arctic C_{3} grass 8 2.2
Cool C_{3} grass 8 5.3
C_{4} grass 8 1.6

For both the Ball-Berry and Medlyn stomatal models the default b_{ft} is 1000 for all PFTs.

1.11.2. Numerical implementation of the Medlyn stomatal conductance model

Photosynthesis is calculated assuming there is negligible capacity to store CO_{2} and water vapor at the leaf surface so that:

A_{n} = \frac{c_{a}-c_{i}}{(1.4r_{b}+1.6r_{s})P_{atm}} = \frac{c_{a}-c_{s}}{1.4r_{b}P_{atm}} = \frac{c_{s}-c_{i}}{1.6r_{s}P_{atm}}

The terms 1.4 and 1.6 are the ratios of diffusivity of CO_{2} to H_{2}O for the leaf boundary layer resistance and stomatal resistance. The transpiration fluxes are related as:

\frac{e_{a}-e_{i}}{r_{b}+r_{s}} = \frac{e_{a}-e_{s}}{r_{b}} = \frac{e_{s}-e_{i}}{r_{s}}

e_{a} = \frac{P_{atm}q_{s}}{0.622}

Parameter Symbol Parameter Name Units indexed by
c_{a} Atmospheric CO_{2} pressure Pa
c_{i} Internal leaf CO_{2} partial pressure Pa
r_{b} Leaf boundary layer resistance s m^2 leaf area \mumol H_{2}O^{-1}
e_{a} Vapor pressure of air Pa
e_{i} Saturation vapor pressure Pa
e_{s} Vapor pressure at the leaf surface Pa
q_{s} Specific humidity of canopy air kg kg ^{-1}

In the Medlyn model, an initial guess of c_{i} is obtained assuming the ratio between c_{i} and c_{a} (0.7 for C_{3} plants and 0.4 for C_{4} plants) to calculate A_n based on Farquhar 1980. Solving for c_{s}:

c_{s} = c_{a}-1.4r_{b}P_{atm}A_{n}

e_{s} can be represented as:

e_{s} = \frac{e_{a}r_{s}+e_{i}r_{b}}{r_{b}+r_{s}}

Where e_{i} is a function of temperature

Substitution of e_{s} following D_{s} = e_{i}-e_{s} gives an expression for stomatal resistance (r_{s}) as a function of photosynthesis (A_{n}), given here in terms of conductance with g_{s} =
\frac{1}{r_{s}} and g_{b} =\frac{1}{r_{b}}

(g_{s})^{2} +  bg_{s} + c = 0

where

b = -[2(b_{ft} \times \beta_{sw}+d)+\frac{(m_{ft})^{2}d^{2}}{g_{b}D_{a}}]

c = (b_{ft} \times \beta_{sw})^{2}+[2g_{0} \times \beta_{sw}+d(1-\frac{{m_{ft}}^{2}}{D_{a}})]d

and

d = \frac{1.6A_{n}}{c_{s}/P_{atm}}

D_{a} = \frac{e_{i}-e_{a}}{1000}

Stomatal conductance is the larger of the two roots that satisfies the quadratic equation. Values for c_{i} are given by:

c_{i} = c_{a} - (1.4r_{b}+1.6r_{s})P_{atm}A_{n}

The equations for c_{i} , c_{s} , r_{s}, and A_{n} are solved iteratively until c_{i} converges. Iteration will be exited if convergence criteria is met or if at least five iterations are completed.

1.11.3. Resolution of stomatal conductance theory in the FATES canopy structure

The stomatal conductance is calculated, as with photosynthesis, for each canopy, PFT and leaf layer. The HLM code requires a single canopy conductance estimate to be generated from the multi-layer multi-PFT array. In previous iterations of the HLM, sun and shade-leaf specific values have been reported and then averaged by their respective leaf areas. In this version, the total canopy condutance G_{s,canopy}, is calculated as the sum of the cohort-level conductance values.

G_{s,canopy} =  \sum{ \frac{gs_{can,coh} n_{coh} }{A_{patch}}}

Cohort conductance is the sum of the inverse of the leaf resistances at each canopy layer (r_{s,z} ) multipled by the area of each cohort.

gs_{can,coh} =\sum_{z=1}^{z=nv,coh}{\frac{ A_{crown,coh}}{r_{s,cl,ft,z}+r_{b}}}

1.12. Control of Leaf Area Index

The leaf area A_{leaf} (m^{2}) of each cohort is calculated from leaf biomass C_{leaf,coh} (kgC individual^{-1}) and specific leaf area (SLA, m^2 kg C^{-1}). Leaf biomass C_{leaf,coh} is controlled by the processes of phenology, allocation and turnover, described in detail in the PARTEH submodule.

A_{leaf,coh} = C_{leaf,coh} \cdot SLA_{ft}

However, using this model, where leaf area and crown area are both functions of diameter, the leaf area index of each tree in a closed canopy forest is always the same (where S_{c,patch} = S_{c,min} , irrespective of the growth conditions. To allow greater plasticity in tree canopy structure, and for tree leaf area index to adapt to prevailing conditions, we implemented a methodology for removing those leaves in the canopy that exist in negative carbon balance. That is, their total annual assimilation rate is insufficient to pay for the turnover and maintenance costs associated with their supportive root and stem tissue, plus the costs of growing the leaf. The tissue turnover maintenance cost (KgC m^{-2} y^{-1} of leaf is the total maintenance demand divided by the leaf area:

L_{cost,coh} = \frac{t_{md,coh}} {C_{leaf,coh} \cdot \textrm{SLA}}

The net uptake for each leaf layer U_{net,z} in (KgC m^{-2} year^{-1}) is

U_{net,coh,z} = g_{coh,z}-r_{m,leaf,coh,z}

where g_{z} is the GPP of each layer of leaves in each tree (KgC m^{-2} year^{-1}), r_{m,leaf,z} is the rate of leaf dark respiration (also KgC m^{-2} year^{-1}). We use an iterative scheme to define the cohort specific canopy trimming fraction C_{trim,coh}, on an annual time-step, where

C_{leaf,coh} =   C_{trim} \times 0.0419  dbh_{coh}^{1.56} d_w^{0.55}

If the annual maintenance cost of the bottom layer of leaves (KgC m-2 year-1) is less than then the canopy is trimmed by an increment \iota_l(0.01), which is applied until the end of next calander year. Because this is an optimality model, there is an issue of the timescale over which net assimilation is evaluated, the timescale of response, and the plasticity of plants to respond to these pressures. These properties should be investigated further in future efforts.

C_{trim,y+1}  = \left\{ \begin{array}{ll}
\rm{max}(C_{trim,y}-\iota_l,1.0)&\rm{for} (L_{cost,coh} > U_{net,coh,nz})\\
&\\
\rm{min}(C_{trim,y}+\iota_l,L_{trim,min})&\rm{for} (L_{cost,coh} < U_{net,coh,nz})\\
\end{array} \right.

We impose an arbitrary minimum value on the scope of canopy trimming of L_{trim,min} (0.5). If plants are able simply to drop all of their canopy in times of stress, with no consequences, then tree mortality from carbon starvation is much less likely to occur because of the greatly reduced maintenance and turnover requirements.

Parameter Symbol Parameter Name Units indexed by
\iota_l Fraction by which leaf mass is reduced next year none
L_{trim,
min} Minimum fraction to which leaf mass can be reduced none

1.13. Phenology

1.13.1. Cold Deciduous Phenology

1.13.1.1. Cold Leaf-out timing

The phenology model of Botta et al. 2000 is used in FATES to determine the leaf-on timing. The Botta et al. model was verified against satellite data and is one of the only globally verified and published models of leaf-out phenology. This model differs from the phenology model in the CLM4.5. The model simulates leaf-on date as a function of the number of growing degree days (GDD), defined by the sum of mean daily temperatures (T_{day} ^{o}C) above a given threshold T_{g} (0 ^{o}C).

GDD=\sum \textrm{max}(T_{day}-T_{g},0)

Budburst occurs when GDD exceeds a threshold (GDD_{crit}). The threshold is modulated by the number of chilling days experienced (NCD) where the mean daily temperature falls below a threshold determined by Botta et al. 2000<botta2000> as 5^{o}C. A greater number of chilling days means that fewer growing degree days are required before budburst:

GDD_{crit}=a+be^{c.NCD}

where a = -68, b= 638 and c=-0.01 Botta et al. 2000<botta2000>. In the Northern Hemisphere, counting of degree days begins on 1st January, and of chilling days on 1st November. The calendar opposite of these dates is used for points in the Southern Hemisphere.

If the growing degree days exceed the critical threshold, leaf-on is triggered by a change in the gridcell phenology status flag S_{phen,grid} where ‘2’ indicates that leaves should come on and ‘1’ indicates that they should fall.

\begin{array}{ll}
S_{phen,grid} = 2
&\textrm{ if } S_{phen,grid} = 1\textrm{ and } GDD_{grid} \ge GDD_{crit} \\
\end{array}

1.13.1.2. Cold Leaf-off timing

The leaf-off model is taken from the Sheffield Dynamic Vegetation Model (SDGVM) and is similar to that for LPJ Sitch et al. 2003 and IBIS Foley et al. 1996 models. The average daily temperatures of the previous 10 day period are stored. Senescence is triggered when the number of days with an average temperature below 7.5^{o} (n_{colddays}) rises above a threshold values n_{crit,cold}, set at 5 days.

\begin{array}{ll}
S_{phen,grid} = 1
&\textrm{ if } S_{phen,grid} = 2\textrm{ and } n_{colddays} \ge n_{crit,cold} \\
\end{array}

1.13.1.3. Global implementation modifications

Because of the global implementation of the cold-deciduous phenology scheme, adjustments must be made to account for the possibility of cold-deciduous plants experiencing situations where no chilling period triggering leaf-off ever happens. If left unaccounted for, these leaves will last indefinitely, resulting in highly unrealistic behaviour. Therefore, we implement two additional rules. Firstly, if the number of days since the last senescence event was triggered is larger than 364, then leaf-off is triggered on that day. Secondly, if no chilling days have occured during the winter accumulation period, then leaf-on is not triggered. This means that in effect, where there are no cold periods, leaves will fall off and not come back on, meaning that cold-deciduous plants can only grow in places where there is a cold season.

Further to this rule, we introduce a ‘buffer’ time periods after leaf-on of 30 days, so that cold-snap periods in the spring cannot trigger a leaf senescence. The 30 day limit is an arbitrary limit. In addition, we constrain growing degree day accumulation to the second half of the year (Jult onwards in the Northern hemisphere, or Jan-June in the Southern) and only allow GDD accumulation while the leaves are off.

1.13.2. Drought-deciduous Phenology: TBD

In the current version of the model, a drought deciduous algorithm exists, but is not yet operational, due to issue detected in the existing CN and soil moisture modules, which also affect the behaviour of the native ED drought deciduous model. This is a priority to address before the science tag is released.

1.13.3. Carbon Dynamics of deciduous plants

In the present version, leaf expansion and senescence happen over the course of a single day. This is clearly not an empirically robust representation of leaf behaviour, whereby leaf expansion occurs over a period of 10-14 days, and senescence over a similar period. This will be incorporated in later versions. When the cold or drought phenological status of the gridcell status changes (S_{phen,grid}) from ‘2’ to ‘1’, and the leaves are still on (S_{phen,coh} =2 ), the leaf biomass at this timestep is ’remembered’ by the model state variable l_{memory,coh}. This provides a ‘target’ biomass for leaf onset at the beginning of the next growing season (it is a target, since depletion of stored carbon in the off season may render achieving the target impossible).

l_{memory,coh} = C_{leaf,coh}

Leaf carbon is then added to the leaf litter flux l_{leaf,coh} (KgC individual^{-1})

l_{leaf,coh} = C_{leaf,coh}

The alive biomass is depleted by the quantity of leaf mass lost, and the leaf biomass is set to zero

C_{alive,coh} = C_{alive,coh} - C_{leaf,coh}

C_{leaf,coh} = 0

Finally, the status S_{phen,coh} is set to 1, indicating that the leaves have fallen off.

For bud burst, or leaf-on, the same occurs in reverse. If the leaves are off (S_{phen,coh}=1) and the phenological status triggers budburst (S_{phen,grid}=2) then the leaf mass is set the maximum of the leaf memory and the available store

C_{leaf,coh} =  \textrm{max}\left(l_{memory,coh}, C_{store,coh}\right.)

this amount of carbon is removed from the store

C_{store,coh} = C_{store,coh}  - C_{leaf,coh}

and the new leaf biomass is added to the alive pool

C_{alive,coh} = C_{alive,coh}  + C_{leaf,coh}

Lastly, the leaf memory variable is set to zero and the phenological status of the cohort back to ‘2’. No parameters are currently required for this carbon accounting scheme.

Parameter Symbol Parameter Name Units indexed by
n_{crit,
cold} Threshold of cold days for senescence none
T_{g} Threshold for counting growing degree days ^{o}C

1.14. Seed Dynamics and Recruitment

The production of seeds and their subsequent germination is a process that must be captured explicitly or implicitly in vegetation models. FATES contains a seed bank model designed to allow the dynamics of seed production and germination to be simulated independently. In the ED1.0 model, seed recruitment occurs in the same timestep as allocation to seeds, which prohibits the survival of a viable seed bank through a period of disturbance or low productivity (winter, drought). In FATES, a plant functional type specific seed bank is tracked in each patch (Seeds_{patch} KgC m^{-2}), whose rate of change (KgC m^{-2} y^{-1}) is the balance of inputs, germination and decay:

\frac{\delta Seeds_{FT}}{\delta t } = Seed_{in,ft} - Seed_{germ,ft} - Seed_{decay,ft}

where Seed_{in}, Seed_{germ} and Seed_{decay} are the production, germination and decay (or onset of inviability) of seeds, all in KgC m^{-2} year^{-1}.

Seeds are assumed to be distributed evenly across the site (in this version of the model), so the total input to the seed pool is therefore the sum of all of the reproductive output of all the cohorts in each patch of the correct PFT type.

Seed_{in,ft} =  \frac{\sum_{p=1}^{n_{patch}}\sum_{i=1}^{n_{coh}}p_{seed,i}.n_{coh}}{area_{site}}

Seed decay is the sum of all the processes that reduce the number of seeds, taken from Lischke et al. 2006. Firstly, the rate at which seeds become inviable is described as a constant rate \phi (y:math:^{-1}) which is set to 0.51, the mean of the parameters used by Lischke et al. 2006.

Seed_{decay,ft} = Seeds_{FT}.\phi

The seed germination flux is also prescribed as a fraction of the existing pool (\alpha_{sgerm}), but with a cap on maximum germination rate \beta_{sgerm}, to prevent excessive dominance of one plant functional type over the seed pool.

Seed_{germ,ft} = \textrm{max}(Seeds_{FT}\cdot \alpha_{sgerm},\beta_{sgerm})

Parameter Symbol Parameter Name Units indexed by
K_s Maximum seed mass kgC m^{-2}
\alpha_{
sgerm} Proportional germination rate none
\beta_{s
germ} Maximum germination rate

KgC m^{-2}

y^{-1}


\phi Decay rate of viable seeds none ft
R_{frac,
ft} Fraction of C_{bal} devoted to reproduction none ft

1.15. Litter Production and Fragmentation

The original CLM4.5 model contains streams of carbon pertaining to different chemical properties of litter (lignin, cellulose and labile streams, specifically). In FATES model, the fire simulation scheme in the SPITFIRE model requires that the model tracks the pools of litter pools that differ with respect to their propensity to burn (surface area-volume ratio, bulk density etc.). Therefore, this model contains more complexity in the representation of coarse woody debris. We also introduce the concept of ’fragmenting’ pools, which are pools that can be burned, but are not available for decomposition or respiration. In this way, we can both maintain above-ground pools that affect the rate of burning, and the lag between tree mortality and availability of woody material for decomposition.
FATES recognizes four classes of litter. Above- and below-ground coarse woody debris (CWD_{AG}, CWD_{BG}) and leaf litter (l_{leaf} and fine root litter l_{root}). All pools are represented per patch, and with units of kGC m{^-2}. Further to this, CWD_{AG}, CWD_{BG} are split into four litter size classes (lsc) for the purposes of proscribing this to the SPITFIRE fire model (seed ’Fuel Load’ section for more detail. 1-hour (twigs), 10-hour (small branches), 100-hour (large branches) and 1000-hour(boles or trunks). 4.5 %, 7.5%, 21 % and 67% of the woody biomass (C_{store,coh} + C_{sw,coh}) is partitioned into each class, respectively.

l_{leaf} and l_{root} are indexed by plant functional type (ft). The rational for indexing leaf and fine root by PFT is that leaf and fine root matter typically vary in their carbon:nitrogen ratio, whereas woody pools typically do not.

Rates of change of litter, all in kGC m{^-2} year^{-1}, are calculated as

\frac{\delta CWD_{AG,out,lsc}}{ \delta t }= CWD_{AG,in,lsc} - CWD_{AG,out,lsc}

\frac{\delta CWD_{BG,out,lsc}}{ \delta t } = CWD_{BG,in,lsc} - CWD_{BG,in,lsc}

\frac{\delta l_{leaf,out,ft} }{ \delta t } = l_{leaf,in,ft} -  l_{leaf,out,ft}

\frac{\delta l_{root,out,ft} }{ \delta t } = l_{root,in,ft} - l_{root,out,ft}

1.15.1. Litter Inputs

Inputs into the litter pools come from tissue turnover, mortality of canopy trees, mortality of understorey trees, mortality of seeds, and leaf senescence of deciduous plants.

l_{leaf,in,ft} =\Big(\sum_{i=1}^{n_{coh,ft}} n_{coh}(l_{md,coh}  + l_{leaf,coh}) + M_{t,coh}.C_{leaf,coh}\Big)/\sum_{p=1}^{n_{pat}}A_{patch}

where l_{md,coh} is the leaf turnover rate for evergreen trees and l_{leaf,coh} is the leaf loss from phenology in that timestep (KgC m^{-2}. M_{t,coh} is the total mortality flux in that timestep (in individuals). For fine root input. n_{coh,ft} is the number of cohorts of functional type ‘FT’ in the current patch.

l_{root,in,ft} =\Big(\sum_{i=1}^{n_{coh,ft}} n_{coh}(r_{md,coh} ) + M_{t,coh}.C_{root,coh}\Big)/\sum_{p=1}^{n_{pat}}A_p

where r_{md,coh} is the root turnover rate. For coarse woody debris input (\mathit{CWD}_{AG,in,lsc} , we first calculate the sum of the mortality M_{t,coh}.(C_{struc,coh}+C_{sw,coh}) and turnover n_{coh}(w_{md,coh}) fluxes, then separate these into size classes and above/below ground fractions using the fixed fractions assigned to each (f_{lsc} and f_{ag})

\mathit{CWD}_{AG,in,lsc} =\Big(f_{lsc}.f_{ag}\sum_{i=1}^{n_{coh,ft}}n_{coh}w_{md,coh}  + M_{t,coh}.(C_{struc,coh}+C_{sw,coh})\Big)/\sum_{p=1}^{n_{pat}}A_p

\mathit{CWD}_{BG,in,lsc} =\Big(f_{lsc}.(1-f_{ag})\sum_{i=1}^{n_{coh,ft}}n_{coh}w_{md,coh}  + M_{t,coh}.(C_{struc,coh}+C_{sw,coh})\Big)/\sum_{p=1}^{n_{pat}}A_p

1.15.2. Litter Outputs

The fragmenting litter pool is available for burning but not for respiration or decomposition. Fragmentation rates are calculated according to a maximum fragmentation rate (\alpha_{cwd,lsc} or \alpha_{litter}) which is ameliorated by a temperature and water dependent scalar S_{tw}. The form of the temperature scalar is taken from the existing CLM4.5BGC decomposition cascade calculations). The water scaler is equal to the water limitation on photosynthesis (since the CLM4.5BGC water scaler pertains to the water potential of individual soil layers, which it is difficult to meaningfully average, given the non-linearities in the impact of soil moisture). The scaler code is modular, and new functions may be implemented trivially. Rate constants for the decay of the litter pools are extremely uncertain in literature, as few studies either separate litter into size classes, nor examine its decomposition under non-limiting moisture and temperature conditions. Thus, these parameters should be considered as part of sensitivity analyses of the model outputs.

\mathit{CWD}_{AG,out,lsc} = CWD_{AG,lsc}. \alpha_{cwd,lsc}.S_{tw}

\mathit{CWD}_{BG,out,lsc} = CWD_{BG,lsc} .\alpha_{cwd,lsc}.S_{tw}

l_{leaf,out,ft} = l_{leaf,ft}.\alpha_{litter}.S_{tw}

l_{root,out,ft} = l_{root,ft}.\alpha_{root,ft}.S_{tw}

1.15.3. Flux into decompsition cascade

Upon fragmentation and release from the litter pool, carbon is transferred into the labile, lignin and cellulose decomposition pools. These pools are vertically resolved in the biogeochemistry model. The movement of carbon into each vertical layer is obviously different for above- and below-ground fragmenting pools. For each layer z and chemical litter type i, we derive a flux from ED into the decomposition cascade as ED_{lit,i,z} (kGC m^{-2} s^{-1})

where t_c is the time conversion factor from years to seconds, f_{lab,l}, f_{cel,l} and f_{lig,l} are the fractions of labile, cellulose and lignin in leaf litter, and f_{lab,r}, f_{cel,r} and f_{lig,r} are their counterparts for root matter. Similarly, l_{prof}, r_{f,prof}and r_{c,prof} are the fractions of leaf, coarse root and fine root matter that are passed into each vertical soil layer z, derived from the CLM(BGC) model.

Parameter Symbol Parameter Name Units indexed by
\alpha_{
cwd,lsc} Maximum fragmentation rate of CWD y^{-1}
\alpha_{
litter} Maximum fragmentation rate of leaf litter y^{-1}
\alpha_{
root} Maximum fragmentation rate of fine root litter y^{-1}
f_{lab,l
} Fraction of leaf mass in labile carbon pool none
f_{cel,l
} Fraction of leaf mass in cellulose carbon pool none
f_{lig,l
} Fraction of leaf mass in lignin carbon pool none
f_{lab,r
} Fraction of root mass in labile carbon pool none
f_{cel,r
} Fraction of root mass in cellulose carbon pool none
f_{lig,r
} Fraction of root mass in lignin carbon pool none
l_{prof,
z} Fraction of leaf matter directed to soil layer z none soil layer
r_{c,pro
f,z} Fraction of coarse root matter directed to soil layer z none soil layer
r_{f,pro
f,z} Fraction of fine root matter directed to soil layer z none soil layer

1.16. Disturbance

FATES allows disturbance through three processes: (1) mortality of canopy trees, (2) fire, (3) anthropogenic disturbance. Each of these is discussed in more detail below. For the case of canopy tree mortality, some fraction of the crown area f_d of deceased trees is used to generate newly-disturbed patch area, while the rest (1-f_d) remains in the existing patch. Thus varying f_d from zero to 1 can lead to three different cases of how mortlaity leads to disturbance. If f_d=1, then all canopy area is converted into newly-disturbed patch area, and a fraction of understory trees equal to the ratio of dying-tree crown are a to the patches area are moved to the newly-disturbed patch, at which time they are promoted to the canopy of the new patch; this is labeled below as the ‘Pure ED’ case. For those trees that are moved to the new patch, some fraction of these will die due to impacts from the disturbance process itself, this fraction i_d is currently a global parameter for all individual-tree disturbance processes, with a default value of 0.55983. If f_d=0, then no disturbance occurs and all mortality is accomodated by promotion of trees from the understory to the canopy within a patch; this is the structure of the PPA formulation as described in Purves et al. 2008, and is labelled below as ‘Pure PPA’. If 0>f_d>1, then some both processes of promotion within a patch and promotion into a new patch occur. A special case of this is when all trees that would be moved into the new patch are killed in the process, thus guaranteeing that newly-disturbed patches are devoid of any surviving trees; this is blabelled below as the ‘bare-ground intermediate case’.

_images/Disturbance_schematic.png

1.17. Plant Mortality

Total plant mortality per cohort M_{t,coh}, (fraction year^{-1}) is simulated as the sum of several additive terms,

M_{t,coh}= M_{b,coh} + M_{cs,coh} + M_{hf,coh} + M_{f,coh} +
M_{i,coh} + M_{fr,coh} + M_{s,coh} + M_{a,coh},

where M_b is the background mortality that is unaccounted by any of the other mortality rates and is fixed at a constant PFT-dependent rate in the parameter file.

M_{cs} is the carbon starvation derived mortality, which is a function of the non-structural carbon storage term C_{store,coh} and the ‘target’ leaf biomass, \grave{C}_{leaf,coh}, as follows:

M_{cs} = \left\{ \begin{array}{ll}
M_{cs,max} (1-C_{store,coh}/\grave{C}_{leaf,coh})& C_{store,coh}<\grave{C}_{leaf,coh}\\
&\\
0& C_{store,coh} >= \grave{C}_{leaf,coh}\\
\end{array} \right.

where M_{cs,max} is the maximum rate of carbon storage mortality parameter, or the maximum rate of trees in a landscape that will die when their carbon stores are exhausted. This parameter is needed to scale from individual-level mortality simulation to grid-cell average conditions.

Thus FATES implicitly assumes that there is a critical storage pool C_{store,coh,critical}=\grave{C}_{leaf,coh} that sets the total-plant storage level where mortality begins; the implied parameter C_{store,coh,critical}/\grave{C}_{leaf,coh}=1 could be made explicit, but we left this as an implicit parameter here due to the generally weak data constraints on it at present. Because both the increase in mortality and the decrease in respiration (see section ‘Respiration’) begin when C_{store,coh} drops below \grave{C}_{leaf,coh}, and \grave{C}_{store,coh} = r_{store} \grave{C}_{leaf,coh}, the parameter r_{store}-1, thus sets the size of the carbon storage buffer that determines how much cumulative negative NPP a plant can experience before it begins to suffer from carbon starvation.

Mechanistic simulation of hydraulic failure is not undertaken on account of it’s mechanistic complexity (see McDowell et al. 2013 for details). Instead, we use a proxy for hydraulic failure induced mortality (M_{hf,coh}) that uses a water potential threshold beyond mortality is triggered, such that the tolerance of low water potentials is a function of plant functional type (as expressed via the \psi_c parameter). For each day that the aggregate water potential falls below a threshold value, a set fraction of the trees are killed. The aggregation of soil moisture potential across the root zone is expressed using the \beta function. We thus determine plant mortality caused by extremely low water potentials as

M_{hf,coh} = \left\{ \begin{array}{ll}
S_{m,ft}& \textrm{for } \beta_{ft} < 10^{-6}\\
&\\
0.0& \textrm{for } \beta_{ft}>= 10^{-6}.\\
\end{array} \right.

The threshold value of 10^{-6} represents a state where the average soil moisture potential is within 10^{-6} of the wilting point (a PFT specific parameter \theta_{w,ft}).

M_{f,coh} is the fire-induced mortality, as described in the fire modelling section.

Impact mortality M_{i,coh} occurs to understory trees that are kille dduring the process of disturbance, as described above.

M_{s,coh} and M_{a,coh} are size- and age-dependent mortality respectively. These terms model a gradual increase in mortality rate with either cohort DBH (cm) or cohort age. We model M_{s,coh} as:

M_{s,coh} = \frac{1}{1 + e^{(-r_s * (DBH - p_s))}}

where DBH is diameter at breast height in cm, r_s is the rate that mortality increases with DBH, and p_s is the inflection point of the curve, i.e. the DBH at which annual mortality rate has increased to 50%. We model M_{a,coh} as :

M_{a,coh} = \frac{1}{1 + e^{(-r_a * (age - p_a))}}

where age is cohort age in years, r_a is the rate that mortality increases with age, and p_a is the inflection point of the curve, i.e. the age at which annual mortality rate has increased to 50%.

Cohort age is not tracked in default FATES. In order to have age-dependent mortality on, set the flag use_fates_cohort_age_tracking to .true. in the FATES namelist options. To turn on either size- or age-dependent mortality set the p and r parameters to sensible values in the FATES parameter file.

Parameter Symbol Parameter Name Units indexed by
S_{m,ft} Stress Mortality Scaler none
l_{targ,ft} Target carbon storage fraction none ft

1.18. Fire (SPITFIRE)

The influence of fire on vegetation is estimated using the SPITFIRE model, which has been modified for use in ED following it’s original implementation in the LPJ-SPITFIRE model (Thonicke et al. 2010, Pfeiffer et al. 2013). This model as described is substantially different from the existing CLM4.5 fire model Li et al. 2012, however, further developments are intended to increase the merging of SPITFIRE’s natural vegetation fire scheme with the fire suppression, forest-clearing and peat fire estimations in the existing model. The coupling to the ED model allows fires to interact with vegetation in a size-structured manner, so small fires can burn only understorey vegetation. Also, the patch structure and representation of succession in the ED model allows the model to track the impacts of fire on different forest stands, therefore removing the problem of area-averaging implicit in area-based DGVMs. The SPITFIRE approach has also been coupled to the LPJ-GUESS individual-based model (Forrest et al. in prep) and so this is not the only implementation of this type of scheme in existence.

The SPITFIRE model operates at a daily timestep and at the patch level, meaning that different litter pools and vegetation charecteristics of open and closed forests can be represented effectively (we omit the patch subscript throughout for simplicity).

1.18.1. Properties of fuel load

Many fire processes are impacted by the properties of the litter pool in the SPITFIRE model. There are one live (live grasses) and five dead fuel categories (dead leaf litter and four pools of coarse woody debris). Coarse woody debris is classified into 1h, 10h, 100h, and 1000h fuels, defined by the order of magnitude of time required for fuel to lose (or gain) 63% of the difference between its current moisture content and the equilibrium moisture content under defined atmospheric conditions. Thonicke et al. 2010. For the purposes of describing the behaviour of fire, we introduce a new index ‘fuel class’ fc, the values of which correspond to each of the six possible fuel categories as follows.

fc index Fuel type Drying Time
1 dead grass n/a
2 twigs 1h fuels
3 small branches 10h fuel
4 large branches 100h fuel
5 stems and trunks 1000h fuel
6 live grasses n/a

1.18.2. Nesterov Index

Dead fuel moisture (\emph{moist}_{df,fc}), and several other properties of fire behaviour, are a function of the ‘Nesterov Index’ (N_{I}) which is an accumulation over time of a function of temperature and humidity (Eqn 5, Thonicke et al. 2010),

N_{I}=\sum{\textrm{max}(T_{d}(T_{d}-D),0)}

where T_{d} is the daily mean temperature in ^{o}C and D is the dew point calculated as .

\begin{aligned}
\upsilon&=&\frac{17.27T_{d}}{237.70+T_{d}}+\log(RH/100)\\
D&=&\frac{237.70\upsilon}{17.27-\upsilon}\end{aligned}

where RH is the relative humidity (%).

On days when the total precipitation exceeds 3.0mm, the Nesterov index accumulator is reset back to zero.

1.18.3. Fuel properties

Total fuel load F_{tot,patch} for a given patch is the sum of the above ground coarse woody debris and the leaf litter, plus the alive grass leaf biomass b_{l,grass} multiplied by the non-mineral fraction (1-M_{f}).

F_{tot,patch}=\left(\sum_{fc=1}^{fc=5}  CWD_{AG,fc}+l_{litter}+b_{l,grass}\right)(1-M_{f})

Many of the model behaviours are affected by the patch-level weighted average properties of the fuel load. Typically, these are calculated in the absence of 1000-h fuels because these do not contribute greatly to fire spread properties.

1.18.3.1. Dead Fuel Moisture Content

Dead fuel moisture is calculated as

\emph{moist}_{df,fc}=e^{-\alpha_{fmc,fc}N_{I}}

where \alpha_{fmc,fc} is a parameter defining how fuel moisture content varies between the first four dead fuel classes.

1.18.3.2. Live grass moisture Content

The live grass fractional moisture content(\emph{moist}_{lg}) is a function of the soil moisture content. (Equation B2 in Thonicke et al. 2010)

\emph{moist}_{lg}=\textrm{max}(0.0,\frac{10}{9}\theta_{30}-\frac{1}{9})

where \theta_{30} is the fractional moisture content of the top 30cm of soil.

1.18.3.3. Patch Fuel Moisture

The total patch fuel moisture is based on the weighted average of the different moisture contents associated with each of the different live grass and dead fuel types available (except 1000-h fuels).

F_{m,patch}=\sum_{fc=1}^{fc=4}  \frac{F_{fc}}{F_{tot}}\emph{moist}_{df,fc}+\frac{b_{l,grass}}{F_{tot}}\emph{moist}_{lg}

1.18.3.4. Effective Fuel Moisture Content

Effective Fuel Moisture Content is used for calculations of fuel consumed, and is a function of the ratio of dead fuel moisture content M_{df,fc} and the moisture of extinction factor, m_{ef,fc}

E_{moist,fc}=\frac{\emph{moist}_{fc}}{m_{ef,fc}}

where the m_{ef} is a function of surface-area to volume ratio.

m_{ef,fc}=0.524-0.066\log_{10}{\sigma_{fc}}

1.18.3.5. Patch Fuel Moisture of Extinction

The patch ‘moisture of extinction’ factor (F_{mef}) is the weighted average of the m_{ef} of the different fuel classes

F_{mef,patch}=\sum_{fc=1}^{fc=5}  \frac{F_{fc}}{F_{tot}}m_{ef,fc}+\frac{b_{l,grass}}{F_{tot}}m_{ef,grass}

1.18.3.6. Patch Fuel Bulk Density

The patch fuel bulk density is the weighted average of the bulk density of the different fuel classes (except 1000-h fuels).

F_{bd,patch}=\sum_{fc=1}^{fc=4} \frac{F_{fc}}{F_{tot}}\beta_{fuel,fc}+\frac{b_{l,grass}}{F_{tot}}\beta_{fuel,lgrass}

where \beta_{fuel,fc} is the bulk density of each fuel size class (kG m^{-3})

1.18.3.7. Patch Fuel Surface Area to Volume

The patch surface area to volume ratio (F_{\sigma}) is the weighted average of the surface area to volume ratios (\sigma_{fuel}) of the different fuel classes (except 1000-h fuels).

F_{\sigma}=\sum_{fc=1}^{fc=4}  \frac{F_{fc}}{F_{tot}}\sigma_{fuel,fc}+\frac{b_{l,grass}}{F_{tot}}\sigma_{fuel,grass}

1.18.4. Forward rate of spread

For each patch and each day, we calculate the rate of forward spread of the fire ros_{f} (nominally in the direction of the wind).

\emph{ros}_{f}=\frac{i_{r}x_{i}(1+\phi_{w})}{F_{bd,patch}e_{ps}q_{ig}}

e_{ps} is the effective heating number (e^{\frac{-4.528}{F_{\sigma,patch}}}). q_{ig} is the heat of pre-ignition (581+2594F_{m}). x_{i} is the propagating flux calculated as (see Thonicke et al. 2010 Appendix A).

x_{i}= \frac{e^{0.792+3.7597F_{\sigma,patch}^{0.5}(\frac{F_{bd,patch}}{p_{d}}+0.1)}}{192+7.9095F_{\sigma,patch}}

\phi_{w} is the influence of windspeed on rate of spread.

\phi_{w}=cb_{w}^{b}.\beta^{-e}

Where b, c and e are all functions of surface-area-volume ratio F_{\sigma,patch}: b=0.15988F_{\sigma,patch}^{0.54}, c=7.47e^{-0.8711F_{\sigma,patch}^{0.55}}, e=0.715e^{-0.01094F_{\sigma,patch}}. b_{w}=196.86W where W is the the windspeed in ms^{-1}, and \beta=\frac{F_{bd}/p_{d}}{0.200395F_{\sigma,patch}^{-0.8189}} where p_{d} is the particle density (513).

i_{r} is the reaction intensity, calculated using the following set of expressions (from Thonicke et al. 2010 Appendix A).:

\begin{aligned}
i_{r}&=&\Gamma_{opt}F_{tot}Hd_{moist}d_{miner}\\
d_{moist}&=&\textrm{max}\Big(0.0,(1-2.59m_{w}+5.11m_{w}^{2}-3.52m_{w}^{3})\Big)\\
m_{w}&=&\frac{F_{m,patch}}{F_{mef,patch}}\\
\Gamma _{opt}&=&\Gamma_{max}\beta^{a}\lambda\\
\Gamma _{max}&=&\frac{1}{0.0591+2.926F_{\sigma,patch}^{-1.5}}\\
\lambda&=&e^{a(1-\beta)}\\
a&=&8.9033F_{\sigma,patch}^{-0.7913}\end{aligned}

\Gamma_{opt} is the residence time of the fire, and d_{miner} is the mineral damping coefficient (=0.174 S_e^{-0.19} , where S_e is 0.01 and so = d_{miner} 0.41739).

1.18.5. Fuel Consumption

The fuel consumption (fraction of biomass pools) of each dead biomass pool in the area affected by fire on a given day (f_{c,dead,fc}) is a function of effective fuel moisture E_{moist,fc} and size class fc (Eqn B1, B4 and B5, Thonicke et al. 2010). The fraction of each fuel class that is consumed decreases as its moisture content relative to its moisture of extinction (E_{moist,fc}) increases.

f_{cdead,fc}=\textrm{max}\left(0,\textrm{min}(1,m_{int,mc,fc}-m_{slope,mc,fc}E_{moist,fc})\Big)\right.

m_{int} and m_{slope} are parameters, the value of which is modulated by both size class fc and by the effective fuel moisture class mc, defined by E_{moist,fc}. m_{int} and m_{slope} are defined for low-, mid-, and high-moisture conditions, the boundaries of which are also functions of the litter size class following Peterson and Ryan 1986 (page 802). The fuel burned, f_{cground,fc} (Kg m^{-2} day^{-1}) iscalculated from f_{cdead,fc} for each fuel class:

f_{cground,fc}=f_{c,dead,fc}(1-M_{f})\frac{F_{fc}}{0.45}

Where 0.45 converts from carbon to biomass. The total fuel consumption, f_{ctot,patch}(Kg m^{-2}), used to calculate fire intensity, is then given by

f_{ctot,patch}=\sum_{fc=1}^{fc=4} f_{c,ground,fc} +  f_{c,ground,lgrass}

There is no contribution from the 1000 hour fuels to the patch-level f_{ctot,patch} used in the fire intensity calculation.

1.18.6. Fire Intensity

Fire intensity at the front of the burning area (I_{surface}, kW m^{-2}) is a function of the total fuel consumed (f_{ctot,patch}) and the rate of spread at the front of the fire, \mathit{ros}_{f} (m min^{-1}) (Eqn 15 Thonicke et al. 2010)

I_{surface}=\frac{0.001}{60}f_{energy} f_{ctot,patch}\mathit{ros}_{f}

where f_{energy} is the energy content of fuel (Kj/Kg - the same, 18000 Kj/Kg for all fuel classes). Fire intensity is used to define whether an ignition is successful. If the fire intensity is greater than 50Kw/m then the ignition is successful.

1.18.7. Fire Duration

Fire duration is a function of the fire danger index with a maximum length of F_{dur,max} (240 minutes in Thonicke et al. 2010 Eqn 14, derived from Canadian Forest Fire Behaviour Predictions Systems)

D_{f}=\textrm{min}\Big(F_{dur,max},\frac{F_{dur,max}}{1+F_{dur,max}e^{-11.06fdi}}\Big)

1.18.8. Fire Danger Index

Fire danger index (fdi) is a representation of the effect of meteorological conditions on the likelihood of a fire. It is calculated for each gridcell as a function of the Nesterov Index . \emph{fdi} is calculated from NI as

\emph{fdi}=1-e^{\alpha N_{I}}

where \alpha = 0.00037 following Venevsky et al. 2002.

1.18.9. Area Burned

Total area burnt is assumed to be in the shape of an ellipse, whose major axis f_{length} (m) is determined by the forward and backward rates of spread (ros_{f} and ros_{b} respectively).

f_{length}=F_{d}(ros_{b}+ros_{f})

ros_{b} is a function of ros_{f} and windspeed (Eqn 10 Thonicke et al. 2010)

ros_{b}=ros_{f}e^{-0.012W}

The minor axis to major axis ratio (i.e. the length-to-breadth ratio) l_{b} of the ellipse is determined by the windspeed. If the windspeed (W) is less than 16.67 m min^{-1} (i.e., 1 km hr ^{-1}) then l_{b}=1. Otherwise (Eqn 12 and 13, Thonicke et al. 2010, Eqn 79 and 80 Canadian Forest Fire Behavior Prediction System Ont.Inf.Rep. ST-X-3, 1992, as corrected in errata reported in Information Report GLC-X-10 by Bottom et al., 2009)

l_{b}= \left\{ \begin{array}{ll}
  1.0+8.729(1.0-e^{-0.108W})^{2.155},   & f_{tree} > 0.55 \\
     &\\
1.1*(3.6W^{0.0464}), & f_{tree} <= 0.55 \\
  \end{array} \right\}

f_{grass} and f_{tree} are the fractions of the patch surface covered by grass and trees respectively.

The total area burned (A_{burn} in m^{2}) is therefore (Eqn 11, Thonicke et al. 2010)

A_{burn}=\frac{n_{f}\frac{3.1416}{4l_{b}}(f_{length}^{2}))}{10000}

where n_{f} is the number of fires.

1.18.10. Crown Damage

c_{k} is the fraction of the crown which is consumed by the fire. This is calculated from scorch height H_{s}, tree height h and the crown fraction parameter F_{crown} (Eqn 17 Thonicke et al. 2010):

c_{k} = \left\{ \begin{array}{ll}
0 & \textrm{for $H_{s}<(h-hF_{crown})$}\\
1-\frac{h-H_{s}}{h-F_{crown}}& \textrm{for $h>H_{s}>(h-hF_{crown})$}\\
1 & \textrm{for $H_{s}>h$ }
\end{array} \right.

The scorch height H_{s} (m) is a function of the fire intensity, following Byram, 1959, and is proportional to a plant functional type specific parameter \alpha_{s,ft} (Eqn 16 Thonicke et al. 2010):

H_{s}=\sum_{FT=1}^{NPFT}{\alpha_{s,p}\cdot f_{biomass,ft}} I_{surface}^{0.667}

where f_{biomass,ft} is the fraction of the above-ground biomass in each plant functional type.

1.18.11. Cambial Damage and Kill

The cambial kill is a function of the fuel consumed f_{c,tot}, the bark thickness t_{b}, and \tau_{l}, the duration of cambial heating (minutes) (Eqn 8, Peterson and Ryan 1986):

\tau_{l}=\sum_{fc=1}^{fc=5}39.4F_{p,c}\frac{10000}{0.45}(1-(1-f_{c,dead,fc})^{0.5})

Bark thickness is a linear function of tree diameter dbh_{coh}, defined by PFT-specific parameters \beta_{1,bt} and \beta_{2,bt} (Eqn 21 Thonicke et al. 2010):

t_{b,coh}=\beta_{1,bt,ft}+\beta_{2,bt,ft}dbh_{coh}

The critical time for cambial kill, \tau_{c} (minutes) is given as (Eqn 20 Thonicke et al. 2010):

\tau_{c}=2.9t_{b}^{2}

The mortality rate caused by cambial heating \tau_{pm} of trees within the area affected by fire is a function of the ratio between \tau_{l} and \tau_{c} (Eqn 19, Thonicke et al. 2010):

\tau_{pm} = \left\{ \begin{array}{ll}
1.0 & \textrm{for } \tau_{1}/\tau_{c}\geq \textrm{2.0}\\
0.563(\tau_{l}/\tau_{c}))-0.125 & \textrm{for } \textrm{2.0} > \tau_{1}/\tau_{c}\ge \textrm{0.22}\\
0.0 & \textrm{for } \tau_{1}/\tau_{c}< \textrm{0.22}\\
\end{array} \right.

Parameter Symbol Parameter Name Units indexed by
\beta_{1
,bt} Intercept of bark thickness function mm FT
\beta_{2
,bt} Slope of bark thickness function mm cm^{-1
} FT
F_{crown
} Ratio of crown height to total height none FT
\alpha_{
fmc} Fuel moisture parameter {^o}C ^{-2} fc
\beta_{f
uel} Fuel Bulk Density kG m^{-3} fc
\sigma_{
fuel,fc} Surface area to volume ratio cm ^{-1} fc
m_{int} Intercept of fuel burned none fc, moisture class
m_{slope
} Slope of fuel burned none fc, moisture class
M_f Fuel Mineral Fraction
F_{dur,m
ax} Maximum Duration of Fire Minutes
f_{energ
y} Energy content of fuel kJ/kG
\alpha_{
s} Flame height parameter   FT

1.19. Wood Harvest (The selective logging module)

Over half of all tropical forests have been cleared or logged, and almost half of standing old-growth tropical forests are designated by national forest services for timber production (Sist et al., 2015). Disturbances that result from logging are known to cause forest degradation at the same magnitude as deforestation each year in terms of both geographic extent and intensity, with widespread collateral damage to remaining trees, vegetation and soils, leading to disturbance to water, energy, and carbon cycling, as well as ecosystem integrity (Keller et al., 2004; Asner et al., 2004).

The selective logging module in FATES mimics the ecological, biophysical, and biogeochemical processes following a logging event. The module (1) specifies the timing and areal extent of a logging event; (2) calculates the fractions of trees that are damaged by direct felling, collateral damage, and infrastructure damage, and adds these size-specific plant mortality types to FATES; (3) splits the logged patch into disturbed and intact new patches; (4) applies the calculated survivorship to cohorts in the disturbed patch; and (5) transports harvested logs off-site by adding the remaining necromass from damaged trees into coarse woody debris and litter pool.

1.19.1. Logging practices

The logging module struture and parameterization is based on detailed field and remote sensing studies (Putz et al., 2008; Asner et al., 2004; Pereira Jr et al., 2002; Asner et al., 2005; Feldpausch et al., 2005). Logging infrastructure including roads, skids, trails, and log decks are represented (Figure 1.17.1). The construction of log decks used to store logs prior to road transport leads to large canopy openings but their contribution to landscape-level gap dynamics is small. In contrast, the canopy gaps caused by tree felling are small but their coverage is spatially extensive at the landscape scale. Variations in logging practices significantly affect the level of disturbance to tropical forest following logging (Pereira Jr et al., 2002; Macpherson et al., 2012; Dykstra, 2002; Putz et al., 2008.

Logging operations in the tropics are often carried out with little planning, and typically use heavy machinery to access the forests accompanied by construction of excessive roads and skid trails, leading to unnecessary tree fall and compaction of the soil. We refer to these typical operations as conventional logging (CL). In contrast, reduced impact logging (RIL) is a practice with extensive pre-harvest planning,where trees are inventoried and mapped out for the most efficient and cost-effective harvest and seed trees are deliberately left on site to facilitate faster recovery. Through planning, the construction of skid trails and roads, soil compaction and disturbance can be minimized. Vines connecting trees are cut and tree-fall directions are controlled to reduce damages to surrounding trees. Reduced impact logging results in consistently less disturbance to forests than conventional logging (Pereira Jr et al. 2002; Putz et al. 2008).

_images/Logging_figure1.png

1.19.2. Mortality associated with logging

The FATES logging module was designed to represent a range of logging practices in field operations at a landscape level. Once logging events are activated, we define three types of mortality associated with logging practices: direct-felling mortality (lmort_{direct}), collateral mortality (lmort _{collateral}), and mechanical mortality (lmort_{mechanical}). The direct felling mortality represents the fraction of trees selected for harvesting that are greater or equal to a diameter threshold (this threshold is defined by the diameter at breast height (DBH) = 1.3 m denoted as DBH_{min}); collateral mortality denotes the fraction of adjacent trees that killed by felling of the harvested trees; and the mechanical mortality represents the fraction of trees killed by construction of log decks, skid trails and roads for accessing the harvested trees, as well as storing and transporting logs offsite (Figure 1.17.1a). In a logging operation, the loggers typically avoid large trees when they build log decks, skids, and trails by knocking down relatively small trees as it is not economical to knock down large trees. Therefore, we implemented another DBH threshold, DBH_{max_{infra}}, so that only a fraction of trees <=DBH_{max_{infra}} (called mechanical damage fraction) are removed for building infrastructure (Feldpausch et al., 2005).

1.19.3. Patch dynamics following logging disturbance

To capture the disturbance mechanisms and degree of damage associated with logging practices at the landscape level, we apply the mortality types following a workflow designed to correspond to field operations. In FATES, as illustrated in Figure 1.17.2., individual trees of all plant functional types (PFTs) in one patch are grouped into cohorts of similar-sized trees, whose size and population sizes evolve in time through processes of recruitment, growth, and mortality. As described abve, cohorts are organized into canopy and understory layers, which are subject to different light conditions (Figure 1.17.2a). When logging activities occur, the canopy trees and a portion of big understory trees lose their crown coverage through direct felling for harvesting logs, or as a result of collateral and mechanical damages ((Figure 1.17.2b). The fractions of (only the) canopy trees affected by the three mortality mechanisms are then summed up to specify the areal percentages of an old (undisturbed) and a new (disturbed) patch caused by logging in the patch fission process (Figure 1.17.2c). After patch fission, the canopy layer over the disturbed patch is removed, while that over the undisturbed patch stays untouched (Figure 1.17.2d). In the undisturbed patch, the survivorship of understory trees is calculated using an understory death fraction consistent with whose default value corresponds to that used for natural disturbance (i_d, 0.559). To differentiate logging from natural disturbance, a slightly elevated, logging-specific understory death fraction is applied in the disturbed patch instead at the time of the logging event. Based on data from field surveys over logged forest plots in southern Amazon (Feldpausch et al., 2005), understory death fraction corresponding to logging is now set to be 0.65 as the default, but can be modified via the FATES parameter file (Figure 1.17.2e). Therefore, the logging operations will change the forest from the undisturbed state shown in Figure 1.17.2a to a disturbed state in Figure 1.17.2f in the logging module. It is worth mentioning that the newly generated patches are tracked according to age since disturbance and will be merged with other patches of similar canopy structure following the patch fusion processes in FATES in later time steps of a simulation, pending the inclusion of separate land-use fractions for managed and unmanaged forest.

_images/Logging_figure2.png

1.19.4. Flow of necromass following logging disturbance

Logging operations affect forest structure and composition, and also carbon cycling (Palace et al., 2008) by modifying the live biomass pools and flow of necromass (Figure 1.17.3). Following a logging event, the logged trunk products from the harvested trees are transported off-site (as an added carbon pool for resource management in the model), while their branches enter the coarse woody debris (CWD) pool, and their leaves and fine roots enter the litter pool. Similarly, trunks and branches of the dead trees caused by collateral and mechanical damages also become CWD, while their leaves and fine roots become litter. Specifically, the densities of dead trees as a result of direct felling, collateral, and mechanical damages in a cohort are calculated as follows:

D_{direct} = lmort_{direct} * n/A

D_{collateral} = lmort_{collateral} * n/A

D_{mechanical} = lmort_{mechanical} * n/A

where A stands for the area of the patch being logged, and n is the number of individuals in the cohort where the mortality types apply (i.e., as specified by the size thresholds, DBH_{min} and DBH_{max_{infra}}). For each cohort, we denote D_{indirect} = D_{collateral} + D_{mechanical} and D_{total} = D_{direct} + D_{indirect}, respectively.

_images/Logging_figure3.png

Leaf litter (Litter_{leaf}, [kg C]) and root litter (Litter_{root}, [kg C]) at the cohort level are then calculated as:

Litter_{leaf} = D_{total} * B_{leaf} * A

D_{leaf} = D_{total} * (B_{root} + B_{store}) * A

where B_{leaf}, B_{root}, B_{store} are live biomass in leaves and fine roots, and stored biomass in the labile carbon reserve in all individual trees in the cohort of interest.

Following the existing CWD structure in FATES (Fisher et al., 2015), CWD in the logging module is first separated into two categories: above-ground CWD and below-ground CWD. Within each category, four size classes are tracked based on their source, following Thonicke et al. (2010): trunks, large branches, small branches and twigs. Above-ground CWD from trunks (CWD_{trunk_{agb}}, [kg C]) and large branches/small branches/twig (CWD_{branch_{agb}}, [kg C]) are calculated as follows:

CWD_{trunk_{agb}} = D_{indiect} * AGB_{stem} * f_{trunk} * A

CWD_{branch_{agb}} = D_{total} * AGB_{stem} * f_{branch} * A

where AGB_{stem} is the amount of above ground stem biomass in the cohort, f_{trunk} and f_{branch} represent the fraction of trunks and large branches/small branches/twig. Similarly, the below-ground CWD from trunks (CWD_{trunk_{bg}}, [kg C]) and branches/twig (CWD_{branch_{bg}}, [kg C]) are calculated as follows:

CWD_{trunk_{bg}} = D_{total} * B_{root_{bg}} * f_{trunk} * A

CWD_{branch_{bg}} = D_{total} * B_{root_{bg}} * f_{branch} * A

where B_{croot} [kg C] is the amount of coarse root biomass in the cohort. Site-level total litter and CWD inputs can then be obtained by integrating the corresponding pools over all the cohorts in the site. To ensure mass conservation,

\delta_B= \delta_{Litter} + \delta_{CWD} + trunk_{product}

where \delta_B is total loss of biomass due to logging, \delta_{litter} and \delta_{CWD} are the increments in litter and CWD pools, and trunk_{product} represents harvested logs shipped offsite.

Following the logging event, the forest structure and composition in terms of cohort distributions, as well as the live biomass and necromass pools are updated. Following this logging event update to forest structure, the native processes simulating physiology, growth and competition for resources in and between cohorts resume. Since the canopy layer is removed in the disturbed patch, the existing understory trees are promoted to the canopy layer, but, in general, the canopy is incompletely filled in by these newly-promoted trees, and thus the canopy does not fully close. Therefore, more light can penetrate and reach the understory layer in the disturbed patch, leading to increases in light-demanding species in the early stage of regeneration, followed by a succession process in which shade tolerant species dominate gradually.

The above describes the case where the canopy is closed (by treees) prior to logging. If this is not the case, some amount of non-tree-occupied canopy area is also moved to the newly-disturbed patch so as to maintain the composition of the undisturbed patch or patches in their original state (albeit in covering a smaller area).

_images/logging_schematic_mixed_open_closed_canopy.png

After logging occurs, the patches that have been disturbed are tracked as belonging to secondary lands, and are not fused with patches on primary lands. This allows primary and secondary land areas to be tracked, with possibly different ecological dynamics occuring on each.

1.20. Plant Hydraulic module

For each plant cohort, the hydraulic module tracks water flow along a soil–plant–atmosphere continuum of a representative individual tree based on hydraulic laws, and updates the water content and potential of leaves, stem, and roots with a 30 minutes model time step. Water flow from each soil layer within the root zone into the plant root system is calculated as a function of the hydraulic conductance as determined by root biomass and root traits such as specific root length, and the difference in water potential between the absorbing roots and the rhizosphere. The root distribution is based on Zeng’s (2001) two parameter power law function which takes into account the regolith depth:

Y_{i} = \frac{0.5(e^{- r_{a}z_{li}} + e^{- r_{b}z_{li}}) - 0.5(e^{- r_{a}z_{ui}} + e^{- r_{b}z_{ui}})}{1 - 0.5(e^{- r_{a}z} + e^{- r_{b}z})}

where Y_{i} is the fraction of fine or coarse roots in the i th soil layer, r_a and r_b are the two parameters that determine the vertical root distribution, z_{li} is the depth of the lower boundary of the i th soil layer, and z_{ui} is the depth of the upper boundary of the i th soil layer, and z is the total regolith depth. The vertical root distribution affects water uptake by the hydrodynamic model by distributing the total amount of root, and thus root resistance, through the soils.

The total transpiration of a tree is the product of total leaf area (LA) and the transpiration rate per unit leaf area J. In this version of FATES-Hydro, we adopt the model developed by Vesala et al. (2017) to take into account the effect of leaf water potential on the within-leaf relative humidity and transpiration rate:

E = LA \cdot J

J = \rho_{atm}\frac{(q_{l} - q_{s})}{1/g_{s} + r_{b}}

q_{l} = \exp(\frac{k_{LWP} \cdot LWP \cdot V_{H2O}}{R \cdot T}) \cdot q_{sat}

Where, E is the total transpiration of a tree, LA [m2] is the total leaf area, J [kg/s/m2] is the transpiration per unit leaf area, \rho [kg/m3] is the density of atmospheric air, q_l [kg/kg] is the within-leaf specific humidity, q_s [kg/kg] is the atmosphere specific humidity, g_s [m/s] is the stoma conductance per unit leaf area, r_b [s/m] is the leaf boundary layer resistance, k_{lwp} is a unitless scaling coefficient, which can vary between 1 and 7, and here we use a value of 3; LWP [Mpa] is the leaf water potential, V_{H2O} [1.8e-6 m3/mol] is the constant molar volume, R is the universal gas constant, and T [K] is the leaf temperature.

The sap flow from absorbing roots to the canopy through each compartment of the tree along the flow path way (absorbing roots, transport roots, stem, and leaf) is computed according to Darcy’s law in terms of the plant sapwood water conductance, the water potential gradient:

Q_{i} = - K_{i}\lbrack\rho_{w}g(z_{i} - z_{i + 1}) + (\Psi_{i} - \Psi_{i + 1})\rbrack

where \rho_{w} is the density of water; z_{i} [m] is the height of the compartment; z_{i + 1} [m] is the height of the next compartment down the flow path; \Psi_{i} [MPa] is the water potential of the compartment; \Psi_{i+1} [MPa] is the water potential of the next compartment down the flow path; and g [kg/MPa/m/s] is the hydraulic conductance of the compartment . The hydraulic conductance of the compartments is by the water potential and maximum hydraulic conductance of the compartment through the pressure-volume (P-V) curve and the vulnerability curve (Manzoni et al. 2013, Christoffersen et al. 2016).

The plant hydrodynamic representation and numerical solver scheme within FATES-HYDRO follows Christoffersen et al. (2016). A few modifications are made to accommodate the multi-soil layers and improve the numerical stability. First, to accommodate the multi-soil layers, we have sequentially solved the Richards’ equation for each individual soil layers, with each layer-specific solution proportional to each layer’s contribution to the total root-soil conductance. Second, to improve the numerical stability, we have linearly interpolated the PV curve beyond the residual and saturated tissue water content to avoid the rare cases of overshooting in the numerical scheme under very dry or wet conditions. Third, Christoffersen et al. (2016) used three phases to describe the PV curves: 1) dehydration phases representing capillary water (sapwood only), 2) elastic cell drainage (positive turgor), and 3) continued drainage after cells have lost turgor. Due to the discontinuity of the curve between these three phases, it leads to some numerical instability. To resolve this instability, FATES-HYDRO added the Van Genuchten model (Van Genuchten 1980, July and Horton 2004) and the Campbell model (Campbell 1974) as an alternatives to describe the PV curves.

The Van Genuchten model has two advantages: 1) it is simple, with only three parameters needed for both curves, and 2) it is mechanistically based, with both the P-V curve and vulnerability curve derived from a pipe model thus are connected through the three shared parameters:

\Psi = \frac{1}{- \alpha} \cdot \left( \frac{1}{Se^{1/m}} - 1 \right)^{1/n}

FMC = \left( 1 - \left( \frac{( - \alpha \cdot \Psi)^{n}}{1 + ( - \alpha \cdot \Psi)^{n}} \right)^{m} \right)^{2}

where \Psi [MPa] is the water potential of the media (xylem in this case); FMC [K/K_{max}] is the fraction of xylem conductivity; \alpha [/MPa] is a scaling parameter for air entering point, Se is the dimensionless standardized relative water content as:

Se =\frac{theta-theta_{r}}{theta_{sat}-theta_{r}}

where \theta, \theta_{r} and \theta_{sat} [m3/m3] are volumetric water content, residual volumetric water content, and saturated volumetric water content correspondingly; and m and n are dimensionless (xylem conduits) size distribution parameters.

The stomatal conductance is modelled in the form of Ball-Berry conductance model (Ball et al. 1987, Oleson et al. 2013, Fisher et al. 2015):

g_{s} = m\frac{A_{n}}{c_{s}/P_{atm}}\frac{e_{s}}{e_{i}} + b\beta_{t}

where m and b are parameters equivalent to slope and intercept in the Ball-Berry model correspondingly. These terms are plant strategy dependent and can vary widely with plant functional types (Medlyn et al. 2011). The parameter b is also scaled by the water stress index \beta_t. A_n [umol CO2/m2/s] is the net carbon assimilation rate based on Farquhar’s (1980) formula. This term is also constrained by water stress index \beta_t in the way that the V_{cmax,25} is scaled by \beta_t as V_{cmax,25}\beta_t (Fisher et al. 2018). c_s [Pa] is the CO2 partial pressure at the leaf surface, e_s [Pa] is the vapor pressure at the leaf surface, e_i [Pa] is the saturation vapor pressure inside the leaf at a given vegetation temperature when A_n = 0.

The water stress index, a proxy for stomatal closure in response to desiccation, is determined by the leaf water potential adopted from the FMCgs term from Christoffersen et al. (2016):

\beta_{t} = \left\lbrack 1 + (\frac{\Psi_{l}}{P50_{gs}})^{ags} \right\rbrack^{- 1}

where \Psi_l [MPa] is the leaf water potential, P50_{gs} [MPa] is the leaf water potential of 50% stomatal closure, and a_{gs} governs the steepness of the function. For a given set of a_{gs} , the P50_{gs} controls the degree of hydraulic vulnerability segmentation (Christoffersen et al. 2016, Powell et al. 2017). A more negative P50_{gs} means that, during leaf dry down from full turgor, the stomatal aperture stays open and thus allows the transpiration rate to remain high and xylem to dry out, which thus can maintain high photosynthetic rates at the risk of exposing xylem to embolism and thus plant mortality. Conversely, a plant with a less negative p50_{gs} will close stomata quickly during leaf dry down, thus limiting transpiration and the risk of xylem embolism and mortality associated with it.

References

Ball, J. Timothy, Ian E. Woodrow, and Joseph A. Berry. 1987. “A model predicting stomatal conductance and its contribution to the control of photosynthesis under different environmental conditions.” Progress in photosynthesis research. Springer, Dordrecht, 221-224.

Campbell, G.S., 1974. A simple method for determining unsaturated conductivity from moisture retention data. Soil science117(6), pp.311-314.

Christoffersen, Bradley O et al. 2016. “Linking Hydraulic Traits to Tropical Forest Function in a Size-Structured and Trait-Driven Model (TFS v . 1-Hydro ).” : 4227–55.

Fisher, R. a. et al. 2015. “Taking off the Training Wheels: The Properties of a Dynamic Vegetation Model without Climate Envelopes, CLM4.5(ED).” Geoscientific Model Development 8(11): 3593–3619.

Jury, W.A. and Horton, R., 2004. Soil physics. John Wiley & Sons.

Manzoni, S., 2014. Integrating plant hydraulics and gas exchange along the drought-response trait spectrum. Tree physiology34(10), pp.1031-1034.

Oleson, Keith W et al. 2013. “Technical Description of Version 4.5 of the Community Land Model (CLM) Coordinating.” In Natl. Cent. Atmos. Res. Tech. Note, Natl. Cent. for Atmos. Res., Boulder, Colo.

Van Genuchten, M.T., 1980. A closed‐form equation for predicting the hydraulic conductivity of unsaturated soils. Soil science society of America journal44(5), pp.892-898.

Vesala, T., Sevanto, S., Gronholm, T., Salmon, Y., Nikinmaa, E., Hari, P., & Holtta, T. 2017. “Effect of leaf water potential on internal humidity and CO2 dissolution: Reverse transpiration and improved water use efficiency under negative pressure.” Frontiers in Plant Science8, 54.

Zeng, Xubin. 2001. “Global Vegetation Root Distribution for Land Modeling.” Journal of Hydrometeorology 2(5): 525–30.
